Description
Technical Specifications: Motor size 025, B-length stator stack, winding code 144, resolver feedback system, 54mm flange size, 40mm centering diameter, continuous standstill torque 0.9Nm, IP65 protection grade, natural convection cooling.
Functional Features: Low rotor inertia, high dynamic response, resolver position feedback for high reliability, compact structure, easy integration, IP65 protection for harsh environments.
Application Scenarios: Small CNC equipment, pick-and-place robots, packaging machinery, electronic assembly automation, sorting equipment.
Performance Parameters: Maximum speed up to 9000rpm, low torque fluctuation, high acceleration capability, stable performance across ambient temperature range 0°C to +40°C.
Material Composition: Cast aluminum housing with heat dissipation ribs, permanent magnet rotor, shaft sealing ring, lifetime lubricated precision bearing.
Structural Features: Flange mounting structure, plain shaft design, resolver integrated at motor rear end, natural heat dissipation ribs on housing surface.
Working Principle: Permanent magnet synchronous motor with resolver feedback, detects rotor angle and position, cooperates with Rexroth digital servo drive to realize closed-loop speed and position control.
Installation Requirements: Flange fixed installation, ensure coaxiality between load and motor shaft, leave sufficient heat dissipation space around housing, route resolver cable separately from power cable.
Notes for Use: Avoid continuous operation under high ambient temperature; prevent dust and water jet entering the motor; avoid mechanical impact on output shaft; do not exceed radial load limit.
