Description
Technical Specifications: 82mm flange size, 50mm centering diameter, continuous standstill torque 2.7Nm, winding code 144, integrated multi-turn absolute Hiperface encoder, IP65 protection class, liquid cooling method, 270° rotatable power connector.
Functional Features: High power density design, fast dynamic response, absolute position feedback, high overload capacity, excellent environmental resistance, integrated shaft seal.
Application Scenarios: CNC machine tools, laser processing equipment, industrial robotics, high-speed automation stations, precision forming machinery.
Performance Parameters: Maximum speed up to 7500rpm, F-class insulation, high rigidity bearing system, low torque ripple, smooth operation at low speed.
Material Composition: High-strength aluminum alloy housing with integrated liquid cooling channels, rare earth permanent magnet rotor, sealed output shaft with sealing ring, high-grade copper winding.
Structural Features: Integrated liquid cooling circuit in housing, plain shaft design, rotatable power and feedback connectors, built-in precision bearing assembly.
Working Principle: Permanent magnet synchronous motor principle, absolute encoder provides high-precision position feedback, realizes full closed-loop motion control matched with Rexroth servo drives.
Installation Requirements: Flange mounting with standard bolts, connect cooling liquid pipeline with specified flow rate, ensure shaft sealing integrity, fix power and feedback connectors properly.
Notes for Use: Control cooling liquid temperature and flow rate within specified range; avoid dry running of cooling circuit; prevent continuous overload operation; protect encoder connector from impact and moisture.
