Product Short Description
Product Overview:
The Indramat TKF3 109-0780-4A01-02 is a tachogenerator designed for use with Rexroth Indramat servo motors, specifically for MAC112D-0-ED-2-C/130-B-1 motors. It functions as a speed feedback device, providing analog voltage proportional to motor rotational speed for closed-loop velocity control.
Description
Key Features:
-
Precision Speed Feedback: Generates analog voltage linearly proportional to shaft speed.
-
Robust Construction: Refurbished units are fully tested and cleaned to OEM standards.
-
Extended Warranty: 24-month warranty on refurbished units.
-
Direct Motor Integration: Specifically designed for MAC112D servo motor series.
Technical Specifications:
|
Parameter
|
Specification
|
|---|---|
|
Brand
|
Bosch Rexroth (Indramat)
|
|
Model
|
TKF3 109-0780-4A01-02
|
|
Product Type
|
Tachogenerator
|
|
Compatible Motor
|
MAC112D-0-ED-2-C/130-B-1
|
|
Weight
|
0.80 kg
|
|
Dimensions (H×L×W)
|
7.0 cm × 15.0 cm × 13.0 cm
|
|
Condition
|
Refurbished, fully tested and cleaned
|
|
Availability
|
Available on request
|
|
Warranty
|
24 months
|
|
Lead Time
|
To order
|
Note: The part number 109-0780-4B01-02 is also referenced as a related/variant model of this tachogenerator.
Working Principle:
As a tachogenerator, it operates on electromagnetic induction—rotating with the motor shaft, it produces a DC voltage directly proportional to rotational speed. This analog signal is fed back to the drive controller for velocity loop regulation.
Application Scenarios:
-
Servo Motor Feedback: Speed sensing for MAC112D series Indramat servo motors.
-
Closed-Loop Motion Control: Velocity feedback in CNC machines, robotics, and precision automation.
-
Legacy System Maintenance: Replacement part for existing Indramat RAC drive systems.
Installation & Usage Notes:
-
Mount directly to the dedicated tachogenerator flange on compatible MAC112D motors.
-
Ensure proper shaft coupling alignment to avoid mechanical stress.
-
Verify polarity and wiring per Indramat TKF3 datasheet.
-
Refurbished units are tested and warranted for 24 months.
