Product Short Description
Product Name: Reliance Electric DC Servo Motor / Tachometer Generator
Product Introduction: The Reliance 5BC42AB2131C is an industrial DC rotating component manufactured by Reliance Electric (now part of Baldor/Rockwell Automation). Based on available documentation, it is identified as a permanent magnet DC servo motor designed for high-precision motion control scenarios, widely used in machine tools, robots, packaging machinery, and printing equipment requiring precise positioning and rapid response.
Description
Technical Specifications:
-
Manufacturer: Reliance Electric (Baldor)
-
Product Type: Permanent Magnet DC Servo Motor
-
Rated Power: 1.5 kW (2.0 HP)
-
Rated Voltage: 240 VDC
-
Rated Current: 6.3 A
-
Rated Speed: 3000 RPM
-
Maximum Speed: 5000 RPM
-
Rated Torque: 4.78 N·m (42.3 lb-in)
-
Peak Torque: 14.34 N·m (126.9 lb-in)
-
Rotor Inertia: 0.0018 kg·m²
-
Insulation Class: F (155°C)
-
Protection Class: IP54 (dust-proof, splash-proof)
-
Cooling Method: Self-cooled (IC410)
-
Mounting: Flange mount (NEMA 42 flange)
-
Shaft Diameter: 28 mm
-
Feedback: Incremental encoder (2000 lines)
-
Working Temperature: -10°C to +40°C
-
Weight: 12.7 kg
-
Compatible Drives: Reliance GV3000, SP500 series
Note: According to nameplate references, this model is also documented as a Tachometer Generator with the following ratings: ambient temperature range -20°C to 80°C, max speed 2750 RPM, measured 180 VDC at 1800 RPM.
Key Features:
-
High torque/inertia ratio with fast dynamic response
-
Peak torque 3× rated for short-term overload capacity
-
F-class insulation with IP54 protection for harsh industrial environments
-
2000-line incremental encoder for micron-level positioning accuracy
Application Scenarios:
-
Machine tools, industrial robots, packaging machinery, printing equipment
-
High-precision positioning and motion control production lines
