BERKELEYA ASM81-B-0B-00-NB10

Description

• Brand: Bosch Rexroth
• Type: Servo Drive Amplifier
• Power Supply: 200–480 VAC, 3-phase
• Continuous Output Current: 10 A
• Peak Output Current: 20 A
• Operating Temperature: 0 °C to 45 °C (32 °F to 113 °F)
• Control Interfaces: Pulse & Direction, Analog ±10 V, SERCOS
• Feedback Interfaces: EnDat, Resolver, Hiperface
• Cooling: Conduction (forced air on heatsink)
• Protection Class: IP20
• Certifications: CE, cULus
• Dimensions: 205 mm × 75 mm × 245 mm (H × W × D)
• Weight: approx. 3.5 kg
• Mounting: Through-bolt, shared heatsink

• 3-phase 200–480 VAC input with 10 A continuous / 20 A peak output
• Multiple control interfaces: Pulse & Direction, Analog ±10 V, and SERCOS
• Supports multiple encoder/feedback types: EnDat, Resolver, Hiperface
• Conduction cooling via shared heatsink for efficient thermal management
• CE and cULus certified for global deployment

• Industrial motion control requiring high precision and dynamic response
• Machine tools, robotics, and automated production lines
• Applications needing SERCOS, analog, or pulse/direction control interfacing

• Must be mounted vertically on a flat, clean heatsink to ensure efficient thermal conduction; apply correct thermal compound and bolt torque to prevent overheating
• Use appropriately sized, shielded cables for both power and feedback; strictly adhere to separation guidelines to keep high-power motor leads away from sensitive signal and encoder wiring
• Always disconnect main power before performing any wiring
• Properly ground the drive chassis, motor frame, and cable shields to a common star point to minimize electrical noise and protect against transient voltages
• Routine maintenance: regularly check cooling fans on the shared heatsink assembly and clean air intake filters; periodically monitor drive’s internal temperature and load parameters via diagnostic software; visually inspect for overheating, loose terminals, or capacitor bulging during scheduled downtime
