Description
-
-
Interface: PROFIBUS-DP
-
Connection Method: EIA-RS-485-compliant
-
Signal Isolation: Isolated
-
Transmission Speed: 9600 bps to 12 Mbps
-
Transmission Route: Shielded
-
Maximum Transmission Distance: 1.2 km per segment (at 9600 bps communication speed)
-
Number of Communication Ports: One port (plus a maintenance port)
-
Communication Port: D-sub 9 pin (female)
-
Maintenance Port: D-sub 9 pin (male), Interface: RS-232C
-
Maximum Current Consumption: 0.7 A
-
Weight: 0.3 kg
-
-
Standards Compliance: The cables and terminators used with this module must comply with PROFIBUS-DP standards (PROFIBUS Specifications IEC 61158-2/EN 50170 volume 2). The PROFIBUS-DP connector used must comply with the PROFIBUS Specification Normative parts-2.
-
Application Scenarios: Industrial process control, power systems, environmental monitoring, and other fields requiring PROFIBUS-DP communication.
-
Installation Requirements: Follow Yokogawa system installation guidelines. Use compliant PROFIBUS-DP cables, terminators, and connectors.
-
Usage Notes: Ensure proper shielding and termination for the PROFIBUS-DP network. Maintain transmission distance limits per segment based on communication speed.
