Yokogawa AFV30D-S41252

Description

Technical Specifications:

• Type: Piston pneumatic actuator (rotary, quarter-turn)
• Action: Spring-return (fail-safe)
• Supply Pressure: 1.4 – 7.0 bar (20 – 100 psi)
• Output Torque: 250 Nm — “25” in model number indicates torque class
• Stroke: 90° (quarter-turn)
• Input Signal: 4–20 mA (via I/P converter) or 20–100 kPa pneumatic
• Ambient Temperature: -20°C to +80°C
• Protection Rating: IP66 / IP67 (NEMA 4X)
• Enclosure: Cast aluminum alloy, epoxy-coated
• Standards: IEC 60534, SIL 2 capable (IEC 61508/61511)

Functional Features:

• Built-in I/P converter (4–20 mA → 20–100 kPa)
• Visual position indicator (0–90°)
• High-torque output for large valves (up to DN200+)
• Lock-up valve for emergency shutdown
• Optional position transmitter (4–20 mA feedback)

Performance Parameters:

• Stroke Time: 5 – 30 seconds (adjustable)
• Air Consumption: <15 Nl/cycle
• Hysteresis: <0.8% of stroke
• Dead Band: <0.3% of stroke
• MTBF: >120,000 hours

Material Composition:

• Housing: Cast aluminum alloy, epoxy-coated
• Piston Seal: PTFE + NBR composite
• Springs: Stainless steel 316
• Shaft: Stainless steel 316
• Fasteners: Stainless steel 316

Structural Features: Direct mount to valve per ISO 5211. Larger and heavier than AFV10D due to piston mechanism. Weight approximately 25–35 kg.

Working Principle: The 4–20 mA signal drives the built-in I/P converter, producing a proportional air pressure that acts on a piston. The piston converts linear force into rotary motion via a rack-and-pinion or scotch-yoke mechanism. The spring provides the fail-safe return. Piston design delivers significantly higher torque than diaphragm types, enabling control of large-bore valves.

Key Advantages: 250 Nm torque handles large valves (DN100–DN300). Built-in I/P converter. SIL 2 certified. Piston design provides higher torque and longer life than diaphragm actuators.

Applicable Industries: Oil & gas (pipeline, refinery), power generation (main steam, feedwater), chemical (large-bore control), LNG.

Model Series: Yokogawa AFV30D Piston Actuator Series

Installation Requirements: Mount per ISO 5211. Ensure valve stem can handle 250 Nm torque. Supply air: clean, dry, oil-free. Install lock-up valve for safety-critical applications.

Usage Precautions: Do not exceed 7 bar supply pressure. Verify torque rating exceeds valve stem torque requirement by at least 20%. Perform annual inspection of piston seals and springs.
