YASKAWA JGSM-06

Technical Core Specifications

1. Power & Electrical Parameters
   • Rated output power: 600 W
   • Rated input voltage: Three-phase AC 200 V
   • Rated speed: 3000 rpm
   • Maximum instantaneous speed: 6000 rpm
   • Rated continuous torque: 1.91 N·m
   • Peak instantaneous overload torque: 5.73 N·m (300% short-time overload capacity)
   • Rotor moment of inertia: 0.38 × 10⁻⁴ kg·m² ultra-low inertia
2. Encoder Feedback System
   • Standard configuration: 17-bit incremental rotary encoder
   • Optional upgrade: 20-bit absolute multi-turn encoder (no backup battery required)
   • Positioning accuracy: ±1 arc-minute repeat positioning precision
3. Mechanical Dimensions & Weight
   • Flange installation size: 60 mm square flange
   • Shaft form: Straight output shaft with flat key and threaded mounting hole
   • Net motor weight: 2.2 kg
4. Environmental Protection Rating
   • Housing protection grade: IP65 (motor body; shaft end IP54)
   • Operating temperature: 0 °C ~ +40 °C
   • Storage temperature: −20 °C ~ +60 °C

Functional Features

1. Ultra-low inertia rotor realizes ultra-fast acceleration response, reaching rated speed within 10 ms
2. Optimized sine wave magnetic circuit suppress torque ripple below 1% for ultra-smooth low-speed stable operation
3. Built-in thermal over-temperature protection thermistor inside stator winding, automatic drive shutdown when winding overheat occurs
4. Optional integrated 24 V DC electromagnetic holding brake for vertical axis load anti-falling positioning
5. Support servo drive real-time auto-gain tuning and mechanical vibration suppression filter function
6. IP65 dustproof and waterproof housing adapts to production line water cleaning and oil mist workshop environment

Working Principle

Material & Structural Composition

• Motor stator core: Cold rolled silicon steel laminated sheet with high magnetic permeability
• Rotor: High-performance rare earth neodymium permanent magnet embedded rotor structure
• Motor housing: Die-cast aluminum alloy with surface anti-corrosion oxidation treatment
• Encoder unit: Sealed dust-proof optical rotary encoder with metal protective shell
• Output shaft: Medium carbon steel quenched and tempered anti-wear transmission shaft with surface rust-proof coating

Advantage Highlights

1. 300% instantaneous overload torque provides powerful instant starting capacity for high inertia load rapid positioning
2. IP65 full body protection eliminates additional protective housing installation cost for harsh production workshop
3. Low torque ripple ensures stable precision conveying of fragile semiconductor and electronic components
4. Complete compatibility with all YASKAWA Σ-II servo drive amplifiers without parameter matching adjustment
5. Compact 60 mm flange small volume saves equipment mechanical structure installation space

Applicable Industries

Installation Mandatory Requirements

1. Motor flange mounting surface flatness tolerance ≤0.02 mm, four fixing bolts torque uniform 4 N·m
2. Coupling connection between motor shaft and load must adopt elastic coupling to avoid rigid transmission axial stress
3. Power cable and encoder feedback cable use dedicated YASKAWA shielded servo cable, separate wiring trough layout
4. Reserve ≥50 mm ventilation gap at motor rear end cover for heat dissipation air circulation

Operation & Maintenance Precautions

1. Avoid continuous operation under 300% overload state over 30 seconds to prevent stator winding insulation aging
2. Regularly check encoder cable connector locking nut tightness to prevent signal loose contact position drift
3. Do not wash motor body with high-pressure water gun directly; only wipe surface with damp soft cloth
4. Replace motor bearing grease every 8000 operating hours for continuous 24-hour production line equipment
