Woodward 2301A 9907-018

Description

• • Power Supply: 18 ~ 32 V DC
  • Operating Temperature: -20 °C ~ +70 °C
  • Frequency Input Range: 50/60 Hz standard industrial frequency
  • Control Output Type: Analog output + Switch output
• Functional Features: Automatic speed regulation, load sharing, overspeed protection, start/stop logic control; Built-in fault detection and alarm function; Manual/Automatic dual control mode.
• Performance Parameters: Speed Regulation Accuracy: ≤ ±0.25% Steady state; Response time ≤ 50 ms; Overspeed protection action threshold is configurable.
• Material Composition: Metal alloy casing with anti-corrosion treatment; High-temperature resistant electronic components; Sealed wiring terminals.
• Structural Characteristics: Integrated sealed structure; Panel mounting type; External wiring terminal row; Built-in potentiometer for parameter manual calibration.
• Working Principle: Collect real-time speed signal of rotating equipment through speed sensor, compare with set target speed, output control signal to actuator to adjust fuel/air intake, realize closed-loop speed stabilization control.
• Advantages & Highlights: High control precision; Strong environmental adaptability; Anti-vibration and anti-corrosion; Long service life; Simple parameter setting.
• Applicable Industries: Power generation, gas turbine unit, diesel generator set, marine power equipment, industrial engine system.
• Model Series: Woodward 2301A Governor Series
• Installation Requirements: Panel embedded installation; Fixed with standard mounting holes; Wiring must use shielded cable; Keep away from high-temperature heat source.
• Usage Notes: Calibrate speed parameters before commissioning; Do not disassemble the sealed casing at will; Regularly inspect sensor signal lines; Avoid strong electromagnetic field interference.
