Product Short Description
Product Introduction
This is an industrial field bus communication module developed for PLC and industrial control systems. It realizes data exchange, protocol conversion and network interconnection between control equipment and upper computer or other field devices, and is used for building industrial automation communication networks.
Description
- Operating Voltage: 24 VDC
- Operating Temperature: 0 °C ~ +60 °C
- Storage Temperature: -25 °C ~ +85 °C
- Communication Protocol: Standard industrial field bus protocol
- Transmission Rate: Adjustable baud rate up to 12 Mbps
- Connection Mode: Bus type network connection
- Mounting Method: Standard DIN rail / PLC backplane mounting
- Protection Class: IP20
- Industrial field bus data transmission and network communication
- Automatic protocol parsing and data packaging
- Communication status self-diagnosis and fault indication
- Data transceiving buffer function to prevent data loss
- Network terminal resistance built-in and switchable
- Isolated communication circuit design
- Maximum Communication Distance: 1000 m (low baud rate)
- Single Network Nodes: Up to 32 nodes
- Data Transmission Accuracy: Bit error rate ≤ 10⁻⁹
- Response Time: ≤ 1 ms
- MTBF: ≥ 460,000 hours
- Housing: Flame-retardant ABS plastic
- Main Board: FR-4 circuit board
- Communication Chip: Industrial bus dedicated communication controller
- Interface Terminal: Copper alloy gold-plated connector
- Isolation Component: High-speed photoelectric isolator
- Compact modular structure, compatible with VIPA PLC series backplane
- Front panel with communication status LED indicators
- Integrated bus terminal resistance switch
- Standard DIN rail locking structure
- Isolated internal circuit layout
The module obtains power and data signal from PLC backplane or external power supply. It converts parallel data inside PLC into serial data complying with field bus protocol and sends to the network. It also receives data from other network nodes, converts into parallel data and transmits to PLC internal bus. The isolated circuit ensures safe data transmission and prevents external interference from affecting the control system.
- High communication speed and long transmission distance
- Built-in isolation circuit with strong anti-interference ability
- Flexible mounting mode, compatible with multiple installation environments
- Stable network operation, low communication failure rate
- Simple network configuration and easy debugging
Factory automated production lines, distributed control systems, intelligent workshop networking, logistics automation systems
- Install on PLC backplane or 35 mm DIN rail and lock firmly.
- Use standard shielded twisted-pair cables for communication wiring.
- Set terminal resistance reasonably according to network length.
- Keep away from high-power equipment and strong electromagnetic sources.
- Do not exceed the maximum number of network nodes and communication distance.
- Cut off power before wiring and module disassembly.
- Check communication indicators regularly during operation.
- Keep the module surface clean and dry.
