SIGMATEK DNC115

Technical Specifications

• Model Series: SIGMATEK DIAS DNC CPU Master Controller Series
• Core Processing Unit: 32-bit dual-core industrial real-time RISC processor
• Onboard Memory: 2 MB RAM, 8 MB non-volatile Flash program storage
• Max Controllable Axis Quantity: 16 synchronous servo/stepper axes via DIAS backplane bus
• Real-Time Logic Cycle Minimum Interval: 0.25 ms
• Motion Control Loop Update Rate: 125 µs multi-axis synchronous PID calculation
• Built-In Communication Interfaces: 1 × Ethernet RJ45, 1 × RS485 DIAS field bus, 1 × USB 2.0 program download port
• Supported Communication Protocols: Modbus TCP, Modbus RTU, SIGMATEK DIAS native bus, OPC UA
• Backplane Bus Standard: SIGMATEK DIAS high-speed internal rack bus
• Rated Supply Voltage: 24 VDC ±10% rack backplane power
• Power Consumption: 14 W full-load operation
• Operating Temperature Range: -20 °C ~ +60 °C
• Storage Temperature Range: -40 °C ~ +85 °C
• Relative Humidity Tolerance: 5%–95% non-condensing
• Mounting Standard: SIGMATEK DIAS standard 35 mm DIN rail rack slot
• Protection Class: IP20 module body
• Dimension: 125 mm (H) × 45 mm (W) × 70 mm (D)
• Net Weight: 420 g

Functional Features

1. Dual-core processor simultaneous execution of PLC logic control and multi-axis high-speed motion trajectory calculation
2. Support complete motion algorithm library: point-to-point positioning, linear/circular interpolation, electronic cam, gantry axis synchronization, jog motion
3. Multi-protocol communication interfaces realize data exchange with HMI, upper SCADA and field DIAS bus I/O modules
4. USB 2.0 local port for offline program download, parameter backup and fault log export without Ethernet connection
5. Hardware multi-stage watchdog circuit to trigger automatic soft reset under program deadlock or bus communication failure
6. Front panel multi-group LED status indicators for power, run, fault, Ethernet and DIAS bus communication status
7. Full hot-swap compatible with all standard DIAS rack backplane slots without full rack power shutdown

Performance Parameters

• Basic Logic Instruction Execution Speed: 0.08 µs per single logic command
• DIAS Backplane Bus Maximum Data Throughput: 16 Mbps
• Ethernet Communication Rate: 10/100 Mbps auto-adaptive
• ESD Surge Withstand Capacity: 2 kV contact discharge for all communication ports
• Vibration Resistance: 10 Hz – 1500 Hz, 5 g continuous cabinet vibration
• Program Storage Data Retention: Permanent storage without backup battery power supply

Material Composition

• Module Housing: Black extruded aluminum alloy with hard anodized anti-corrosion coating
• Main Control PCB: FR4 multi-layer low-crosstalk industrial fiberglass circuit board with conformal insulation coating
• Communication Connectors: Industrial shielded gold-plated RJ45 and USB sockets
• Backplane Gold Finger: Gold-plated phosphor bronze anti-oxidation edge connector
• Terminal Blocks: Nickel-plated brass screw terminals for auxiliary power wiring
• Passive Heat Dissipation: Integrated aluminum heat sink bonded to core processor chip

Structural Characteristics

1. Standard narrow 45 mm width DIN rail rack plug-in single-slot module structure
2. Front panel segmented layout: communication ports, LED status indicator array, USB download port
3. Rear edge gold finger connector for direct electrical docking with DIAS rack internal backplane bus
4. Physically separated internal circuit compartments for processor core, Ethernet communication and DIAS bus circuits to eliminate signal crosstalk
5. Dual side elastic locking latches for fixed installation inside DIAS rack slots to resist cabinet vibration
6. Distributed top and bottom ventilation slits for natural convection passive cooling

Working Principle

Advantage Highlights

1. Integrated PLC logic and multi-axis motion control in single narrow slot module to reduce rack slot occupation quantity
2. Ultra-fast 0.25 ms minimum logic cycle supports high-speed automated production line synchronous control
3. Multi-channel multi-protocol communication interfaces eliminate external gateway hardware for upper system connection
4. Hot-swap maintenance design allows module replacement without shutting down the entire automation rack
5. Wide -20 °C ~ +60 °C operating temperature adapts to unheated industrial workshop control cabinets
6. Full mechanical and electrical compatibility with all SIGMATEK DIAS series I/O, draw-wire sensor and axis control modules

Applicable Industries

Installation Requirements

1. Insert DNC115 into any vacant standard slot of SIGMATEK DIAS DIN rail rack; lock dual side latches tightly to fix module position
2. Maintain minimum 10 mm vertical ventilation gap between DNC115 and adjacent rack modules for heat dissipation
3. Separate Ethernet and DIAS bus communication cables from high-power inverter and motor power wiring with minimum 20 cm clearance
4. Implement single-point PE grounding of all shielded communication cables at cabinet main PE bar; grounding resistance ≤ 4 Ω
5. Verify stable 24 VDC backplane power supply before executing hot-swap replacement of the module
6. Control cabinet internal continuous operating temperature below 55 °C during full-load multi-axis operation

Operation & Maintenance Precautions

1. ESD anti-static wrist strap mandatory during module disassembly, program download and wiring modification
2. Complete full backup of PLC logic and motion parameter files before module replacement to avoid reconfiguration workload
3. Conduct semi-annual inspection of Ethernet and USB port contacts for dust and oxide accumulation
4. Do not install DNC115 adjacent to high-frequency welding equipment and large AC drive inverters
5. Store spare DNC115 modules in sealed anti-static packaging with silica gel desiccant packs
6. Cut off rack backplane 24 VDC power supply before removing the module from DIAS rack slot
