Product Name: Sigmatek 05-008-163 Digital I/O Module
Product Series: Sigmatek Standard Automation I/O Module Series
Product Brief: Compact combined digital input and output module for Sigmatek PLC system. It realizes on-site switching signal acquisition and on-off control output, applied to logic control tasks of various automated machinery and equipment.
Description
- Rated Supply Voltage: 24 V DC
- Operating Temperature: -20 °C ~ +68 °C
- Storage Temperature: -35 °C ~ +82 °C
- Relative Humidity: 5% ~ 95% RH (Non-condensing)
- Input Channel Quantity: 8 channels
- Output Channel Quantity: 8 channels
- Single Channel Output Current: 0.4 A
- Response Time: ≤ 0.35 ms
- Integrated digital input and output, realize signal collection and control output simultaneously
- Over-current, short-circuit and reverse voltage protection for all channels
- Independent LED status indication for each channel
- Hardware signal filtering to suppress field interference
- Support Sigmatek real-time industrial bus communication
- Total Power Consumption: ≤ 7.5 W
- Insulation Resistance: ≥ 95 MΩ
- Vibration Resistance: 10 Hz ~ 170 Hz, 1 g
- Shock Resistance: 16 g peak acceleration
- MTBF: ≥ 102000 hours
- Main PCB: FR-4 high-temperature resistant PCB
- Shell: Flame-retardant engineering plastic
- Core Devices: Industrial optocouplers, drive transistors, protection components
- Terminals: Vibration-resistant combined terminal blocks
- Internal Wiring: High-temperature resistant insulated wires
- Standard DIN rail modular structure
- Integrated input and output terminals arranged on front panel
- Compact integrated layout, small overall dimension
- Built-in metal shielding sheet for electromagnetic interference suppression
- Snap-type assembly structure for combination with other modules
Field digital switching signals are collected by input circuits and transmitted to the main control unit after isolation and filtering. Control commands from the main unit are converted into switching signals by output drive circuits to control external actuators. Protection circuits act immediately when electrical faults occur on channels.
- Combined I/O design, reduce module quantity and wiring workload
- Compact size, highly space-saving in control cabinet
- Comprehensive protection functions, high operation safety
- Stable bus communication, good compatibility with Sigmatek system
- Strong environmental adaptability for general industrial workshops
Packaging machinery, woodworking machinery, conveying equipment, automation assembly, plastic machinery, printing machinery
- Install on 35 mm standard DIN rail in control cabinet
- Keep ventilation space around the module, no blocking
- Signal lines and power lines shall be routed in different wire ducts
- Complete reliable protective grounding
- Install away from high-power frequency conversion equipment
- Do not overload output channels beyond rated current
- All wiring operations must be performed under power-off state
- Check terminal connection tightness periodically
- Avoid using in environment with corrosive gas and conductive dust
- Do not modify internal circuit structure arbitrarily
