Product Short Description
Product Introduction: This is a core electronic control board for SEW-EURODRIVE distributed drive systems, widely used in MOVIMOT series frequency inverters. It acts as the “brain” of the drive system, receiving control commands from a PLC or fieldbus and precisely regulating motor speed, torque, and operating status. The MDV 8222215.14.17 is part of the modular vector servo drive platform (MDV), originally factory-discontinued and now available as imported industrial spare parts.
Description
Technical Specifications:
-
Manufacturer: SEW-EURODRIVE
-
Full Model: MDV 8222215.14.17
-
Product Type: MOVIDRIVE MDV series servo drive encoder feedback main control board
-
Input Voltage: 220 VAC ±15%
-
Output Power: 7.5 kW
-
Frequency Range: 0–30 kHz
-
Protection Class: IP20
-
Compatible Drives: MDF60A / MDV60A / MDS60A
-
Communication Protocols: PROFIBUS / DeviceNet / AS-i
-
Interface Types: Bus interface / Analog / Digital
-
Mounting: Plug-in / DIN rail mounting
-
Operating Temperature: -10°C to +40°C (board-level spec: 0°C to 55°C)
-
Certifications: CE, UL
Functional Features:
-
Sensorless Vector Control: Uses high-performance microprocessor and optimized algorithms for excellent dynamic response and low-speed torque
-
Flexible Communication: Hot-swappable bus interface modules; supports PROFIBUS-DP, DeviceNet, AS-Interface
-
Dual Encoder Support: Absolute encoder and resolver can be connected simultaneously for multi-axis synchronization and electronic cam closed-loop control
-
Comprehensive I/O: DB9 communication port (DFU debug, RS485 Modbus RTU, CANopen); left terminal block for digital DI/DO, analog 0–10 V speed/torque, 24 VDC supply, motor thermistor TF protection; backplane gold finger for PWM drive pulses, DC bus voltage, current sampling
-
Status Indicators: POWER, RUN, FAULT, ENCODER, BUS
Application Scenarios: Conveyor systems, production lines, packaging machinery, material handling, manufacturing, and process control systems.
Installation Requirements: Professional installation required. Plug-in / DIN rail mounting.
Usage Notes:
-
Avoid conductive dust and moisture
-
Use certified power components
-
Rapid dynamic torque control with built-in brake chopper
-
Compact modular design with fieldbus communication interfaces
