Description
Technical Specifications
- Output Channels: 4 independent analog outputs
- Output Signal Ranges: ±10 V DC (voltage), 4–20 mA DC (current)
- Resolution: 16-bit signed data format
- Accuracy: ±0.2% full scale at 25 °C
- Load Capacity: Max 1 μF (capacitive load)
- Power Supply: 24 V DC ±10%
- Current Consumption: 120 mA (typical)
- Operating Temperature: -10 °C ~ +55 °C
- Storage Temperature: -25 °C ~ +70 °C
- Protection Class: IP20
- Dimensions (L×W×H): 120 mm × 45 mm × 30 mm
- Weight: 0.2 kg
Structural Features
Compact modular design, standard 35 mm DIN rail mounting base, screw terminal block for field wiring, integrated circuit board with anti-vibration coating, flame-retardant ABS plastic housing with metal shielding.
Functional Characteristics
Provides stable analog voltage/current outputs for closed-loop control of valves, variable frequency drives, and actuators; supports isolated signal transmission and fault diagnosis.
Working Principle
Converts digital control signals from the PLC into precision analog outputs via a 16-bit DAC; includes signal conditioning and overvoltage protection circuits to ensure stable driving of external loads.
Material Composition
- Housing: Flame-retardant ABS plastic (UL94 V-0)
- Internal PCB: FR-4 high-temperature resistant substrate
- Terminals: Tin-plated copper alloy
- Shielding: Cold-rolled steel sheet with anti-rust coating
Advantages & Highlights
High output accuracy and stability, strong anti-electromagnetic interference, wide signal range compatibility, plug-and-play installation, polarity reversal protection, seamless integration with Schneider Quantum/Momentum PLCs.
Applicable Industries
Industrial automation, process control, water treatment, packaging machinery, textile equipment, building automation, food and beverage production.
Installation Requirements
- Mount vertically on a standard 35 mm DIN rail.
- Maintain a 20 mm ventilation gap around the module.
- Separate power and signal wiring to avoid interference.
- Install in a dry, dust-free control cabinet.
Usage Notes
- Do not exceed the rated voltage/current range.
- Disconnect power before wiring or maintenance.
- Avoid mechanical shock and excessive vibration.
- Periodically check terminal tightness and clean dust.
