SAACKE HMI10-M REV203

Technical Specifications

• Display Diagonal Size: 10-inch TFT color touch screen
• Display Resolution: 800 × 480 pixel industrial grade LCD
• Touch Type: Resistive analog touch panel, glove operation compatible
• Supply Voltage: 24V DC ±10% industrial control power supply
• Communication Interfaces: RS485 Modbus RTU, Saacke proprietary combustion bus
• Firmware Version Locked: REV203 factory pre-flashed, dedicated combustion algorithm library
• Storage Capacity: Onboard 128MB flash memory for fault log and trend data storage

Functional Features

1. Real-time monitoring of burner flame signal, fuel valve status, air-fuel ratio, exhaust temperature
2. On-screen parameter modification of ignition timing, proportional combustion regulation, safety interlock thresholds
3. Complete combustion fault historical log storage with timestamp recording
4. Multi-level user access password management (operator, maintenance, administrator permission tiers)
5. Analog trend curve display for continuous combustion process data recording
6. REV203 revision optimized low-flame unstable combustion anti-jitter algorithm

Performance Parameters

• Operating ambient temperature: 0°C ~ +55°C
• Storage temperature: -20°C ~ +70°C
• Front panel IP grade: IP65 dust and splash water resistance
• Back housing IP grade: IP20 indoor cabinet installation
• Touch screen service life: 1,000,000 standard touch actuation cycles
• Data log retention time: 5 years non-volatile storage without power supply
• EMC compliance: IEC 61000-6-2 industrial heavy interference standard

Material Composition

• Front operation panel: Tempered anti-scratch glass + ABS flame-retardant frame
• Rear control housing: Flame-retardant ABS plastic UL94 V-0
• Internal mainboard: Industrial FR4 PCB with conformal coating anti-moisture protection
• Connector terminals: Copper alloy gold-plated signal pins
• Mounting gasket: EPDM rubber sealing strip for panel cutout waterproofing

Structural Characteristics

• Panel embedded flush mounting structure for boiler control cabinet front cutout
• Single rear wiring compartment isolating power and signal terminals
• Horizontal rectangular standard industry cutout dimension
• Integrated LED power and fault status indicator on rear housing

Working Principle

Advantage Highlights

1. Purpose-built for thermal combustion systems with preloaded boiler/burner dedicated interface menus
2. REV203 firmware eliminates early revision flame signal reading instability defects
3. IP65 front panel withstands boiler room water splash, dust and high humidity environment
4. Resistive touch supports operation with oily work gloves without touch failure
5. Built-in long-term data logging eliminates external data recorder hardware cost

Applicable Industries

Installation Requirements

1. Cabinet panel cutout dimension strictly match factory specified outline drawing
2. Install complete EPDM sealing gasket between HMI frame and cabinet metal panel
3. 24V DC power supply must equip 2A fuse short-circuit protection
4. Signal wiring use shielded twisted pair cable, shield single-end grounded at cabinet earth bar
5. Maintain minimum 100mm ventilation clearance behind rear housing for heat dissipation

Operation & Maintenance Precautions

1. Only use neutral water-based microfiber cloth to clean touch screen, alcohol solvent prohibited
2. Firmware REV203 cannot be downgraded; cross-revision firmware flash causes permanent function loss
3. Monthly export fault log data to external storage for combustion system performance analysis
4. Avoid direct high-temperature steam blowing onto front glass panel
5. Replace EPDM sealing gasket every 2 years to prevent water ingress cabinet damage
