RPSTECH DMP10.24

Technical Specifications

• Model Series: RPSTECH DMP Compact DIN Rail Power Supply Series
• Rated Output Power: 10 W
• Nominal Output Voltage: 24 VDC
• Output Current Rating: 0.42 A continuous
• Input Voltage Range: 85 VAC ~ 264 VAC universal single-phase mains
• Input Frequency Compatibility: 47 Hz ~ 63 Hz
• Efficiency Rating: 84% full-load conversion efficiency
• Overvoltage Protection Threshold: 29 VDC auto-shutdown
• Overcurrent Protection: 120% output current auto current limiting
• Short-Circuit Protection: Continuous auto-recovery short-circuit shutdown
• Hold-Up Time: ≥ 10 ms at 110 VAC input full load
• Operating Temperature Range: -20 °C ~ +60 °C
• Storage Temperature Range: -40 °C ~ +85 °C
• Relative Humidity Tolerance: 5%–95% non-condensing
• Mounting Standard: 35 mm standard DIN rail
• Protection Class: IP20 module body for cabinet internal installation
• Overall Dimension: 90 mm (H) × 32 mm (W) × 58 mm (D)
• Net Weight: 135 g

Functional Features

1. Universal wide-range AC input supports global single-phase industrial mains without voltage adjustment jumper
2. Integrated three-layer safety protection circuit: overvoltage, overcurrent and auto-recovery short-circuit protection
3. Low residual ripple noise design for stable power supply to high-precision analog signal sensors
4. Built-in power status LED indicator on front panel for visual power operation monitoring
5. Compact narrow 32 mm width reduces cabinet horizontal space occupation
6. Integrated EMI filtering circuit to suppress mains conducted electromagnetic interference
7. Full compliance with industrial safety standard IEC 61010-1 for control cabinet electrical equipment

Performance Parameters

• Output Voltage Ripple Noise: ≤ 120 mVpp full rated load
• Voltage Regulation Deviation: ±1% no-load to full-load output fluctuation
• Isolation Voltage: 3000 VAC between input mains circuit and DC output circuit
• MTBF Service Life: 120,000 hours under 25 °C continuous operating environment
• Surge Withstand Capacity: 2 kV EFT for AC input mains port
• Vibration Resistance: 10 Hz – 150 Hz, 1 g continuous cabinet vibration

Material Composition

• Outer Enclosure: Flame-retardant V0 grade black ABS plastic housing with anti-flame retardant additives
• Internal Transformer: High-frequency ferrite core switching transformer with insulated copper winding
• Main Circuit PCB: FR4 single-layer industrial fiberglass circuit board with conformal insulation coating
• Input/Output Terminal Blocks: Nickel-plated brass anti-oxidation screw terminals
• DIN Rail Clip: Elastic glass-fiber reinforced PA plastic locking clip for rail mounting
• Heat Dissipation Components: Passive copper heat sink strips for power switching MOSFET

Structural Characteristics

1. Narrow slim rectangular DIN rail form factor optimized for dense multi-power-supply cabinet layout
2. Front panel centralized layout of AC input terminals, DC output terminals and power status LED indicator
3. Independent internal compartment separation between high-voltage AC input circuit and low-voltage DC output circuit with insulation barrier
4. Elastic locking DIN rail clip mounted on rear housing for one-hand rapid installation and removal from 35 mm standard rail
5. Multiple passive ventilation slits distributed on top and bottom housing surfaces for natural convection heat dissipation
6. Standard M3 screw mounting holes reserved for fixed wall mounting without DIN rail

Working Principle

Advantage Highlights

1. Ultra-compact narrow body design saves cabinet horizontal installation space for multi-module stacking
2. 85–264 VAC wide universal input compatible with all global factory single-phase power grids
3. Auto-recovery short-circuit protection eliminates manual power cycle reset after wiring short fault
4. Low ripple output ensures stable power supply for high-precision analog displacement and temperature sensors
5. Passive natural heat dissipation structure eliminates fan maintenance and noise interference
6. Dual installation modes (DIN rail / wall fixed) adapt to diversified cabinet layout requirements

Applicable Industries

Installation Requirements

1. Fasten RPSTECH DMP10.24 onto standard 35 mm top-hat DIN rail via rear elastic locking clip; confirm full clip engagement to avoid sliding
2. Reserve minimum 8 mm horizontal clearance between adjacent power supply modules for cross-module heat dissipation
3. Separate AC input mains wiring from DC output signal wiring inside cabinet with minimum 10 cm distance to avoid interference coupling
4. Connect cabinet PE ground bar to power supply dedicated ground terminal; grounding resistance ≤ 4 Ω
5. Limit total DC load power below rated 10 W to prevent long-term overload aging
6. Maintain cabinet internal continuous operating temperature below 55 °C to extend service life

Operation & Maintenance Precautions

1. Cut off upstream AC mains power before disassembly of input and output wiring terminals
2. Conduct annual inspection of terminal block screw tightness to eliminate loose contact heating risks
3. Do not install adjacent to high-power frequency converters and contactors to avoid mains surge interference
4. Regularly clean housing ventilation slits with dry compressed air to remove dust accumulation blocking heat dissipation
5. Store spare units in dry sealed packaging to prevent plastic housing aging and circuit board moisture corrosion
6. Strictly prohibit parallel connection of multiple DMP10.24 output terminals to expand load current
