Product Short Description
Product Introduction
This is a dedicated digital main control board for Reliance industrial AC/DC drives. It undertakes core operation, logic control and signal processing work of the drive system, receives external command signals, operates control algorithms and outputs driving signals to power units. It is a core control component of industrial speed regulation and drive equipment.
Description
- Working Power Supply: 5 VDC / 15 VDC dual power supply
- Operating Temperature: 0 °C ~ +60 °C
- Storage Temperature: -30 °C ~ +80 °C
- Input Signal: Analog signal, switch signal, encoder feedback signal
- Output Signal: PWM control signal, drive logic signal
- Isolation Strength: 1000 VAC
- Board Type: Plug-in type main control board
- Core digital algorithm operation for drive speed regulation and torque control
- Multi-channel external command signal acquisition and processing
- Encoder speed and position feedback signal processing
- Drive system fault detection and fault code output
- Parameter storage and logic sequence control
- Signal isolation and anti-interference processing
- Signal Sampling Frequency: 10 kHz
- Control Operation Cycle: 100 μs
- Working Stability: Long-term continuous operation without drift
- Anti-interference Performance: Compliant with industrial EMC standards
- Service Life: ≥ 40,000 working hours
- Circuit Board: Thickened FR-4 industrial circuit substrate
- Main Control Chip: Industrial-grade single-chip microcomputer and logic operation chip
- Signal Devices: Photoelectric isolators, operational amplifiers
- Connectors: Tin-plated high-current connectors
- Passive Components: High-temperature resistant resistors and capacitors
- Standard plug-in board structure, suitable for drive internal card slot installation
- Partition layout of control area, signal acquisition area and output area
- Reinforced board body structure, anti-vibration for industrial operation
- Standard positioning pins and anti-misplug design
- Centralized wiring terminals for signal and power lines
After power-on, the board initializes internal programs and parameters. It collects external speed commands, feedback signals and status signals in real time, completes algorithm operation and logic judgment through the main control chip, and outputs PWM and logic control signals to the power drive unit. Meanwhile, it monitors the operating status of the whole drive system, judges fault types and outputs alarm signals when abnormal conditions appear, and stores fault information locally.
- High operation speed and stable control performance
- Strong anti-vibration and anti-interference capability for industrial sites
- Standard plug-in design, convenient for replacement and maintenance
- Perfect matching with Reliance series drives
- Accurate signal processing to guarantee drive operation precision
Industrial motor speed regulation systems, fan and pump energy-saving transformation, metallurgical transmission equipment, chemical production line drives
- Insert the board into the dedicated card slot of the drive, ensure full contact of connectors.
- Keep the installation position well ventilated for heat dissipation.
- Complete installation after cutting off drive total power.
- Avoid installation in areas with severe dust and oil mist.
- Do not operate beyond rated temperature range.
- Take anti-static protection measures during disassembly and assembly.
- Prohibit liquid and conductive foreign matter from falling onto the board.
- Replace in time when continuous signal failure or logic error occurs.
