Description
- Product Category: Extended Safety Control Module
- Safety Standard: Compliant with EN ISO 13849, IEC 61508
- Expansion Channel: Multi-group safety signal input and expansion interface
Functional Features:
- Expand the number of access points of safety peripheral devices
- Realize multi-group safety signal logic linkage
- Cooperate with main safety relay to complete complex safety control
- Output safety status signal to upper system
Performance Parameters:
- Rated Operating Voltage: 24V DC
- Operating Temperature: 0°C to 60°C
- Communication Compatibility: Dedicated bus communication with Pilz safety system
Material Composition: Industrial safety-grade chip, flame-retardant PCB, insulated plastic housing, anti-loose terminal block
Structural Characteristics: DIN rail mounting modular design, cascading interface for system expansion, LED status indication area, distributed terminal area for different signal channels
Working Principle: Acts as the expansion unit of the main safety system, accesses more safety detection signals, performs preset safety logic judgment together with the main safety relay, realizes linkage protection of multiple equipment and multiple safety areas, and feeds back overall system safety status.
Advantages & Highlights:
- Flexible system expansion, suitable for large-scale multi-station safety systems
- Consistent safety level with main safety products, unified protection standard
- Stable cascading communication, no signal delay in linkage action
- Unified installation and maintenance with Pilz safety series products
Applicable Industries: Large automated production line, intelligent workshop, logistics handling equipment, multi-station machining center
Model Series: Pilz Extended Safety Module Series
Installation Requirements:
- Install adjacent to main safety relay module on DIN rail
- Complete cascading connection between modules as required
- Perform full system safety linkage test after wiring
Usage Notes:
- Ensure reliable cascading connection between modules
- Regularly check status indicators of each channel
- It is forbidden to change safety logic setting without authorization
