PARKER DR1008B-230

Description

Material Composition

• Outer housing: Black cold-rolled steel sheet metal anti-corrosion coated casing
• Drive circuit substrate: High-current industrial power PCB with copper thickened conductive traces
• Power drive components: High-temperature IGBT power switching chips
• Signal isolation components: Linear optocoupler isolation modules
• Terminal block: Nickel-plated copper alloy spring wire clamping terminals
• Heat sink: Built-in aluminum alloy power tube heat dissipation fin

Structural Features

1. Standard DIN rail mounting compact rectangular unit form factor for electrical control cabinet installation
2. Front panel integrated channel status LED indicator group and digital parameter adjustment potentiometers
3. Separate terminal blocks for 230 VAC mains power input, analog control signal input and proportional valve drive output
4. Internal built-in aluminum fin heat sink for power IGBT heat dissipation
5. Independent signal isolation zone separates low-voltage control signal circuit and high-current power drive circuit
6. Overheat protection temperature sensing probe attached to power heat sink surface

Technical Specifications

• Model Number: DR1008B-230
• Power Supply Input: 230 VAC single-phase mains power, 50/60 Hz
• Channel Configuration: 8 independent proportional valve drive output channels
• Single Channel Rated Drive Current: 0–2 A continuous adjustable PWM output current
• Control Signal Input Standard: 0–10 VDC analog voltage signal, 4–20 mA analog current signal dual compatible
• PWM Switching Frequency: 1.2 kHz fixed drive frequency
• Signal Isolation Voltage (Control ↔ Power Drive): 1000 VAC dielectric withstand
• Operating Temperature Range: 0 ℃ ~ +55 ℃
• Storage Temperature Range: -25 ℃ ~ +70 ℃
• Maximum Power Consumption Full Load: 120 VA
• DIN Rail Mounting Standard: EN 60715 35 mm standard top hat rail
• Unit Dimension: 160 mm (L) × 110 mm (W) × 45 mm (D)
• Net Weight: 0.78 kg

Function Features

1. 8 independent fully isolated proportional valve drive channels, no cross-channel signal interference during simultaneous multi-valve regulation
2. Dual-mode analog control signal input compatibility (0–10 V / 4–20 mA) matching all mainstream industrial PLC analog output modules
3. Front panel independent potentiometer for each channel zero offset and gain parameter manual adjustment
4. Built-in overcurrent, short-circuit, overheat and mains overvoltage multi-layer protection circuit
5. Channel fault LED alarm for output short circuit, valve coil open circuit and drive overcurrent state
6. Closed-loop current feedback control for each channel ensures stable valve drive current under hydraulic load fluctuation
