Description
Technical Specifications
- Rated Power: 5.2 kW
- Rated Voltage: Standard Servo Working Voltage
- Rated Speed: Special Customized Speed Grade
- Torque Rating: Enhanced Continuous Torque
- Insulation Class: Class H
- Protection Class: IP66
- Operating Temperature: -25 °C ~ +85 °C
- Shaft Configuration: Special customized shaft and mounting interface
Structural Features
Reinforced cast aluminum shell, enhanced sealed structure, high temperature resistant winding, customized output shaft and installation flange, heavy-duty bearing assembly, high-shock resistant rear encoder structure.
Functional Characteristics
High-precision servo drive, support high-load and long-time continuous operation; realize closed-loop position, speed and torque control, adapt to harsh working conditions.
Working Principle
Stator winding generates rotating magnetic field to drive permanent magnet rotor to rotate; high-resolution encoder collects real-time position and speed signals and feeds back to servo driver to realize full closed-loop precise control.
Material Composition
Shell: High strength die-cast aluminum alloy; Winding: Class H high temperature resistant enameled copper wire; Rotor: Rare earth permanent magnet + high strength alloy shaft; Bearing: Heavy-duty anti-wear bearing; Sealing part: Wear-resistant rubber sealing ring.
Advantages & Highlights
Enhanced high temperature resistance and shock resistance, larger allowable load range, more stable continuous operation, better dustproof and waterproof performance, suitable for harsh industrial sites, long service life.
Applicable Industries
Heavy-duty automation equipment, metallurgical machinery, mining auxiliary equipment, outdoor industrial equipment, high-load processing machinery, harsh environment production line.
Installation Requirements
- Use customized flange for fixed installation, fasteners shall reach specified torque.
- Strictly control coaxiality between motor and load to reduce vibration.
- Use high tensile resistant special cables for wiring, fix cables firmly.
- Avoid installation in strong corrosion and strong vibration area.
Usage Notes
- Regularly inspect sealing performance to prevent dust, water and oil from entering the motor.
- Do not start frequently under extreme overload state.
- Check the operation vibration and temperature rise regularly.
- Maintain encoder protection cover integrity at all times.
