NI PCI-8517

Description

Technical Specifications:

• Number of Ports: 2 fully functional FlexRay interfaces
• Transceiver: 2× TJA1080 FlexRay transceivers
• Baud Rate Range: 1 Mbps to 10 Mbps
• Bus Interface: 32-bit PCI bus
• Part Number: 780685-02
• Supported Operating Systems: Windows, LabVIEW RT
• Programming Support: LabVIEW, C/C++ Functional Features:
• Part of NI-XNET platform with unified API for CAN, LIN, and FlexRay
• Supports cold-start functionality to connect individual ECUs without other cold-start nodes
• Two independent interfaces can connect to separate FlexRay networks simultaneously
• High-speed real-time processing of hundreds of FlexRay frames and signals Application Scenarios:
• Hardware-in-the-loop simulation
• Rapid control prototyping
• FlexRay bus monitoring and analysis
• Automotive ECU testing
• Vehicle communication system development Material Composition:
• Automotive-grade FlexRay transceivers
• Industrial-grade PCB with EMC protection Structural Features:
• Standard PCI form factor
• Standard automotive connector interfaces Working Principle: The device connects to FlexRay automotive networks, handles physical layer communication via onboard transceivers, and processes FlexRay protocol frames in real time. The NI-XNET driver provides a high-level API for host applications to read and write FlexRay signals and frames. Installation Requirements:
• Installs in standard 32-bit PCI expansion slot
• Requires FlexRay-compatible cabling and connectors
• NI-XNET driver software required for operation Usage Notes:
• Ensure proper bus termination on FlexRay networks
• Follow automotive ESD and EMC guidelines for vehicle connections
• Use only NI-certified cables for optimal performance
