Description
Technical & Performance Parameters
- Processor: MPC603, 200MHz
- Main Memory: 16MB ECC DRAM
- Boot Storage: On-board Flash memory for bootstrap firmware
- Expansion: Dual PMC mezzanine card sites
- VME Controller: Universe II ASIC, supporting VME64 protocols
- I/O Routing: PMC I/O signals routed to front panel and VME P2 connector
- Operating Temperature: 0°C ~ 70°C
- Form Factor: Single slot 6U VME
Functional Features
- Dual independent PCI buses for PMC peripherals to avoid bandwidth contention
- Comprehensive interrupt control for real-time task scheduling
- Support rear transition module I/O via P2 backplane connector
- Compatible with extensive third-party PMC I/O modules
Working Principle
PowerPC processor operates on local PCI bus; Universe II bridge connects PCI domain to VME backplane. PMC modules add dedicated peripherals such as multi-channel serial adapters, Ethernet and fieldbus interfaces.
Application Scenarios
Industrial automation controllers, communications signal processing, automated test equipment, shipboard auxiliary control systems.
Installation Requirements
- Confirm mechanical compatibility between PMC modules and chassis airflow
- Configure PCI interrupt routing via firmware during initial setup
