Product Short Description
Product Introduction: The MOOG CZ1008DVA is a multifunctional servo drive module primarily used for precise control of DC servo motor speed, position, and force. It features a modular design for easy expansion and integration into complex industrial automation systems. The unit is also available as a 2-way, 3-position (normally closed) servo proportional flow control valve engineered for precise flow control in industrial hydraulic systems.
Description
Technical Specifications:
| Parameter | Specification |
|---|---|
| Model Number | CZ1008DVA |
| Manufacturer | Moog Inc. |
| Product Type | Servo Drive Module / Servo Proportional Valve |
| Voltage Range | 24 VDC to 80 VDC |
| Continuous Current | 8A |
| Peak Current | 16A |
| Maximum Power | 640W |
| Speed Range | 0 to 3000 RPM |
| Control Modes | Position, Speed, and Torque control |
| Dimensions | 230 x 170 x 80 mm |
| Valve Type | 2-way, 3-position (normally closed) servo proportional |
| Rated Force (Actuator Version) | 8000 N |
| Rated Stroke (Actuator Version) | ±100 mm |
| Rated Speed (Actuator Version) | 100 mm/s |
| Working Pressure (Actuator Version) | 210 bar |
| Operating Temperature (Actuator Version) | -55°C to +125°C |
Functional Features:
-
Advanced digital signal processing technology for极高 precision position, speed, and torque control
-
Modular design for easy expansion and system integration
-
Supports multiple control modes: Position, Speed, and Torque
-
High-power capability up to 640W
-
Wide voltage range for flexible configuration
-
Precise flow control for industrial hydraulic systems
Performance Parameters:
-
8A continuous current, 16A peak current
-
640W maximum power
-
0-3000 RPM speed range
-
8000N rated force (actuator version)
-
±100mm rated stroke (actuator version)
Material Composition: Industrial-grade components for demanding applications
Structural Features:
-
Modular design for easy expansion
-
Compact form factor: 230 x 170 x 80 mm
-
Servo proportional valve configuration available
Working Principle: The CZ1008DVA utilizes advanced digital signal processing to control DC servo motors with极高 precision in position, speed, and torque. It converts digital control signals into precise motor drive currents, with continuous current up to 8A and peak current up to 16A. The module operates across a voltage range of 24-80 VDC and supports multiple control modes for different application requirements.
Advantages and Strengths:
-
High-precision digital signal processing control
-
Modular design for flexible system integration
-
Multiple control modes for versatile applications
-
High power capability up to 640W
-
Wide operating voltage range
-
Suitable for aircraft control systems
Applicable Industries:
-
Aircraft control systems
-
Industrial automation systems
-
Hydraulic flow control systems
-
DC servo motor control applications
Model Series: MOOG CZ Series (CZ1008DVA)
Installation Requirements:
-
Modular installation for easy integration
-
Requires appropriate power supply (24-80 VDC)
Usage Precautions:
-
Available in multiple configurations (servo drive module or servo proportional valve)
-
Verify specific configuration and specifications for the intended application
-
Operating temperature range varies by configuration (-55°C to +125°C for actuator version)
