Product Name: SST-PB3-CLX-RLL PROFIBUS DP Communication Module for ControlLogix
Product Overview:
Slot-based communication module for Rockwell Automation ControlLogix 1756 backplane. It enables ControlLogix PLC to communicate with PROFIBUS DP remote I/O and field instruments.
Description
- Backplane Compatibility: Allen‑Bradley 1756 ControlLogix chassis
- PROFIBUS Port: 1 channel D-SUB 9 female connector
- Operation Mode: PROFIBUS DP Master or DP Slave
- Baud Rate: Up to 12 Mbps
- Operating Temperature: -40°C ~ +70°C
- Module Weight: 430 g
Function Features:
Supplied with AOP Add-On Profile for RSLogix 5000 programming environment; module front panel LED for network, fault and activity status; cyclic data exchange between Logix controller tags and PROFIBUS nodes.
Application Scenarios:
Rockwell ControlLogix automation projects requiring connection to PROFIBUS DP devices, packaging machinery, process plant control systems.
Structural Characteristics:
Standard 1756 single-slot module form factor, directly pluggable into ControlLogix rack backplane.
Installation Requirements:
Power off chassis before plugging/unplugging module. Import AOP file into programming software before project configuration.
Usage Notes:
Use PROFIBUS shielded cable; properly set station address and bus termination resistor.
