Product Name: 10.4″ Industrial Human-Machine Interface (HMI) Touch Panel
Overview: The MICRO INNOVATION GF1-10TVD-102 is a high-reliability industrial HMI terminal with a 10.4-inch TFT touchscreen. It supports dual RS-485/422, RS-232, Ethernet, and USB interfaces, making it suitable for complex PLC systems and multi-device coordination.
Description
Technical Specifications:
- Display: 10.4″ TFT, 800 × 600 (SVGA), LED backlight, 65K colors
- Brightness: 300 cd/m²
- Contrast Ratio: 500:1
- Viewing Angle: 70°/70° (H), 60°/70° (V)
- Backlight Life: ≥ 30,000 hours
- Touch Type: 4-wire analog resistive (supports glove/stylus operation)
- Processor: High-performance ARM embedded CPU (typical 500–600 MHz)
- RAM: 128 MB
- Flash Storage: 256 MB (user available ≥ 128 MB)
- Real-Time Clock: Built-in with supercapacitor or battery backup
- Communication Interfaces:
- 1 × RS-232 (COM1)
- 2 × RS-485/422 (COM2 & COM3, software switchable)
- 1 × 10/100 Mbps Ethernet
- 1 × USB 2.0 Host
- Supported Protocols: Modbus RTU/ASCII/TCP, Siemens S7-200/300/1200/1500, Mitsubishi FX/Q/L, Omron Host Link/FINS, Allen-Bradley MicroLogix/CompactLogix (DF1/PCCC), Delta, Panasonic, Yaskawa, GE Fanuc, custom protocols via macro/script
- Development Software: EasyBuilder Pro (free, graphical configuration)
- Power Supply: DC 24 V ±15% (ripple <5%)
- Power Consumption: ≤ 18 W
- Protection Rating: Front panel IP65, rear IP20, metal housing
- Operating Temperature: -10 °C to +60 °C
- EMC Compliance: EN 61000-6-2/-4
- Certifications: CE, FCC, RoHS
- Mounting: Panel-embedded (cutout: 243 × 183 mm)
- Warranty: 24-month limited warranty
Key Features:
- Enhanced communication (dual RS-485) for multi-PLC connection
- Large user storage (256 MB Flash)
- Enhanced power management and EMC performance
- Resistive touch supports industrial gloves
- Free graphical configuration software
Application Scenarios: Multi-PLC collaborative production lines, water treatment stations, energy management systems, packaging and printing machinery.
Working Principle: The HMI acts as an operator interface between personnel and control systems. It communicates with PLCs and field devices via serial, Ethernet, or USB, displaying real-time process data, accepting operator inputs, and logging historical data.
Installation & Notes:
- Panel cutout: 243 × 183 mm
- Provide DC 24 V ±15% with ripple <5%
- Front panel IP65 sealed — ensure proper gasket compression during panel mounting
- Use shielded cables for RS-485 in high-noise environments
- Follow CAN bus topology rules if applicable — avoid star connections
- Match output contact capacity to load parameters to prevent overload damage
