Bus Interface: PCI 32-bit / 33 MHz, plug-and-play
-
Video Input: RGB analog, composite NTSC/PAL, S-Video, RS-170/CCIR
-
Simultaneous Channels: Up to 8 video inputs (depending on configuration)
-
Sampling: 8-bit A/D per channel, independently sampled
-
Color Depth: 24-bit true color (8 bit/channel)
-
Frame Buffer: Onboard 8 MB / 16 MB SDRAM (version-dependent), double-buffered
-
Acquisition Modes: Real-time continuous, triggered acquisition, external synchronization
-
Trigger Input: TTL hardware trigger; software trigger supported
-
Graphics Overlay: Real-time true-color graphics overlay on live video; separate Y/C or RGB output
-
Display Output: VGA display up to 1280×1024
-
Power: ≤ 5 W, PCI bus-powered (no external supply needed)
-
Form Factor: Standard PCI half-length card (~170 × 107 mm)
-
SDK: Matrox Imaging Library (MIL), Active MIL, MIL-Lite, Matrox Inspector
-
OS Support: Windows (32/64-bit), Linux
-
Application Fields:
-
Industrial automation visual inspection & positioning
-
Video surveillance, recording & broadcast
-
Test & measurement, signal acquisition
-
Legacy system replacement / spare parts for aging vision systems
-
Key Advantages: Fan-less, low-power, long-term stable operation; MIL SDK for easy secondary development; pure acquisition (no local playback output)
-
Installation: Insert into a free PCI slot; install MIL driver suite; configure acquisition via Matrox Intellicam or custom MIL application.
