LAM 810-091934-00

Description

• • Input Channels: 8 sensor inputs
  • Voltage: 5 VDC (sensors), 24 VDC (logic)
  • Operating Temperature: -20 °C to +70 °C
  • Dimensions: 220 mm × 180 mm × 20 mm
• Functional Features:
  • Signal Amplification: High-gain amplifiers for weak sensor signals.
  • Threshold Detection: Adjustable threshold for edge detection.
  • Digital Outputs: 8 digital outputs (24 VDC) for edge presence signals.
  • LED Indicators: Per-channel LEDs for sensor status.
• Performance Parameters:
  • Detection Resolution: 0.01 mm
  • Response Time: <10 μs
  • Adjustment Range: Threshold adjustable via potentiometers
• Material Composition:
  • PCB: FR-4, 1.6 mm, ESD-protected
  • Amplifiers: High-speed operational amplifiers
  • Connectors: 8 × M12 sensor connectors, terminal blocks
• Structural Characteristics:
  • Compact Design: 220 mm × 180 mm, panel-mountable
  • Front Panel: Sensor connectors, status LEDs, potentiometers
  • Enclosure: Optional aluminum enclosure for protection
• Working Principle: Receives analog signals from optical edge sensors, amplifies and conditions the signals, compares them to adjustable thresholds, and outputs digital signals indicating the presence of a wafer edge.
• Advantages:
  • High Resolution: Enables precise wafer edge detection for alignment.
  • Fast Response: Critical for high-speed wafer handling.
  • Easy Adjustment: Potentiometers for on-site threshold calibration.
• Applicable Industries: Semiconductor manufacturing (wafer handling), electronics assembly, precision automation.
• Model Series: 810 Series (Lam Research Sensor Interface PCBA Series)
• Installation Requirements:
  • Mount near the edge sensors for short cable runs.
  • Connect 5 VDC (sensors) and 24 VDC (logic) power.
• Usage Notes:
  • Keep optical sensors clean for accurate detection.
  • Avoid exposing the board to direct laser light.
