Product Short Description
Product Name: KUKA Robot Cable Assembly
Product Series: KUKA Industrial Robot Peripheral Cable Series
Product Brief Introduction: Dedicated power and signal integrated cable assembly for KUKA industrial robots, used for power supply and signal transmission between robot body and control cabinet.
Description
- Cable Structure: Composite cable (power core + signal shielded core)
- Rated Voltage: 600 V AC
- Rated Current: 16 A per power core
- Shielding Type: Double-layer copper braided shielding
- Minimum Bending Radius: 10 × cable outer diameter (dynamic bending)
- Operating Frequency: DC ~ 60 Hz
Functional Features: Integrated power transmission and control signal transmission; anti-torsion, anti-bending, anti-abrasion; electromagnetic shielding; oil resistance and coolant resistance.
Performance Parameters:
- Operating Temperature: -30 °C ~ +80 °C
- Dynamic Bending Lifespan: ≥ 10 million cycles
- Tensile Strength: ≥ 1500 N
- Flame Retardant Grade: VW-1
Material Composition: TPE outer sheath; high-flex stranded copper conductor; cross-linked polyethylene insulation layer; copper mesh shielding layer; reinforced tensile fiber core.
Structural Features: Integrated one-piece assembly with dedicated connectors at both ends; flexible stranded conductor design for robot joint movement; sealed connector structure; anti-pinching cable routing design.
Working Principle: Transmit working power to each joint servo motor of the robot; transmit encoder signals, limit switch signals and control feedback signals between robot body and control cabinet through internal shielded cores.
Advantages & Highlights: Professional robot dynamic bending design; excellent anti-interference performance; long service life in cyclic motion; fully matched with KUKA robot interfaces; resistant to industrial oil and chemical liquids.
Applicable Industries: Automotive manufacturing, welding workshop, handling robot workstation, intelligent factory, metal processing, automotive assembly line.
Installation Requirements: Follow the robot cable routing path strictly; fix cable clamps according to official layout; reserve sufficient bending margin for robot full-stroke movement; align connector pins accurately during connection.
Usage Notes: Avoid sharp edge friction and heavy extrusion; do not over-tighten cable clamps; inspect sheath abrasion regularly; replace immediately if connector sealing fails.
