Product Short Description
Product Brief Introduction
Special industrial motion control core module independently developed by Japan KOKUSAI Electric, exclusively matched with semiconductor wafer etching, deposition and cleaning process equipment. It executes multi-axis servo motor closed-loop motion control, equipment logic interlock and real-time process signal acquisition for 300mm/200mm wafer fabrication production lines, integrating signal input/output and industrial communication functions in single compact unit.
Description
Core Technical Performance Parameters
- Rated Operating Input Voltage: 24VDC industrial DC power supply ±10% tolerance
- Power Consumption: Maximum 18W full-load operation
- Motion Control Axis Support: Up to 8-axis servo motor synchronous closed-loop control
- Onboard Digital I/O Channels: 16-channel DI (24VDC sink/source compatible), 16-channel DO transistor output
- Analog Signal Interface: 4-channel 0–10V analog input, 2-channel 0–10V analog output
- Communication Interfaces: 10/100Mbps auto-adaptive Ethernet port, RS485 serial port, CANopen industrial bus interface
- Supported Serial Baud Rates: 9600bps, 19200bps, 38400bps, 115200bps adjustable
- Operating Temperature Range: -30°C ~ +65°C equipment cabinet ambient
- Storage Temperature: -40°C ~ +85°C
- Relative Humidity: 20% ~ 80% non-condensing, no corrosive gas environment
- Vibration Resistance: 0.5g acceleration 10–120Hz frequency band
- Protection Class: IP30 sealed metal housing for semiconductor cleanroom cabinet mounting
Functional Features
- High-speed multi-axis motion control algorithm optimized for semiconductor wafer handling robot linear and rotary positioning
- Real-time equipment safety interlock logic processing for wafer chamber door, vacuum pressure and gas supply fault protection
- Built-in high-precision analog signal sampling circuit for vacuum gauge, temperature sensor and flow meter measurement
- Ethernet communication supports data upload to fab host MES production management system
- CANopen bus interface for direct connection to servo drive units, realizing distributed motion control architecture
- Onboard non-volatile flash memory stores wafer process motion recipes and equipment fault historical logs
- Multi-channel LED status indicators for power supply, bus communication, axis motion running, fault alarm and digital channel activity
- Hardware over-voltage, over-current and reverse power connection protection circuit to prevent module burnout from field wiring error
Working Principle
24VDC power supply inputs to module internal isolated power conversion circuit to generate multi-group stable working voltage for motion control CPU, signal acquisition chips and communication transceivers. 32-bit industrial RISC main processor executes preloaded wafer handling motion control programs, outputs pulse/direction or CANopen motion commands to external servo drives to control wafer transfer robot positioning. Onboard analog front-end circuits continuously sample process sensor signals (vacuum, temperature, gas flow); digital input channels collect equipment safety interlock switch signals, all data is processed in real-time and uploaded to factory MES system via Ethernet. If safety interlock fault signal triggers, internal logic immediately stops all axis motion and outputs fault alarm digital signal to cabinet indicator lamp.
Material Composition & Structural Characteristics
- Outer Enclosure: Sealed extruded aluminum alloy housing with fin heat dissipation structure, matte black anti-static coating for semiconductor cleanroom anti-particle requirement
- Internal Circuit Board: Multi-layer FR4 PCB with gold-plated low-particle contact terminals, anti-corrosion surface treatment
- Heat Dissipation Structure: Integrated vertical aluminum cooling fins on module housing for passive heat dissipation without cooling fan
- Connection Interfaces: IP30 rated metal circular industrial connectors for power, servo bus and signal wiring
- Mounting Form: Standard DIN rail industrial cabinet mounting structure
Installation Requirements
- DIN rail vertical installation inside semiconductor equipment electrical cabinet, cleanroom Class 1000 or higher environment
- Maintain minimum 25mm vertical ventilation gap above and below module cooling fins
- All signal wiring must use shielded twisted-pair cable with single-point cabinet grounding
- Separate power cables and signal cables in different cable trays to avoid motion control signal interference
- Cabinet ambient temperature must not exceed 65°C continuous operation
Application Scenarios
- KOKUSAI vertical thermal processing wafer furnace equipment motion control
- Semiconductor etching chamber wafer transfer robot positioning control
- Thin film deposition PVD/CVD equipment wafer handling interlock control
- Wafer wet cleaning process automation logic and motion control system
- 200mm/300mm integrated circuit fabrication fab front-end process equipment
Operation & Maintenance Precautions
- Module housing must not be disassembled in cleanroom environment to avoid particle contamination of wafer production equipment
- Cut off 24VDC power supply before connecting or disconnecting all external wiring connectors
- Do not expose module to corrosive fluorine or chlorine process gas leakage environment
- Wipe aluminum cooling fin dust with lint-free cleanroom cloth quarterly
- Backup wafer motion recipe data to external MES storage before module replacement or firmware upgrade
- Firmware upgrade operation must be executed when equipment is offline without wafer processing production
