Product Short Description
Product Introduction
Modular rack-mounted multi-loop industrial process controller for continuous chemical, petrochemical and energy plant distributed control sub-systems, supporting multi-channel temperature, pressure and flow closed-loop PID regulation, configurable fieldbus communication and comprehensive process alarm management. Full suffix string denotes complete factory configuration variant with specified I/O count, communication protocol and housing hardware.
Description
Technical Specifications
- Controllable PID Loop Count: 15 independent simultaneous closed control loops
- Universal Analog Input Channels: 50 isolated universal analog signal input terminals
- Configurable Output Types: Relay contact, SSR drive, 4–20mA analog output configurable per channel
- Fieldbus Communication Protocol: HART 7, FOUNDATION Fieldbus H1 dual protocol support (suffix H0 designation)
- Mounting Form Factor: 19-inch standard industrial rack 8U height chassis
- System Power Supply: 110/240V AC dual universal mains power input redundant supply
- Operating Cabinet Temperature: 0°C ~ +60°C continuous operation
- Dielectric Isolation Rating: 3000V DC channel-to-chassis isolation for all analog inputs
Functional Features
- Independent self-tune PID algorithm for each of 15 process control loops
- Multi-variable mathematical calculation logic for compensated flow, heat energy totalization
- Full HART 7 two-way digital communication with smart field transmitters for remote calibration
- Hierarchical multi-level process alarm system with time-stamped event data logging
- Redundant dual power supply input support for uninterrupted plant control operation
- Front panel touch LCD graphical display for loop setpoint adjustment and real-time trend viewing
Performance Parameters
- Single Loop Control Steady-State Accuracy: ±0.1% full scale process variable
- Analog Input Conversion Resolution: 18-bit high precision ADC per sampling channel
- Fieldbus Communication Update Rate: 250ms full loop data refresh cycle
- Event Log Storage Capacity: 10,000 time-stamped alarm event records non-volatile storage
Material Composition
19-inch rack chassis cold-rolled steel powder coated anti-corrosion housing, FR-4 multilayer control PCB, silicon isolation transformers, industrial grade LCD touch display module, nickel-plated heavy-duty screw terminal blocks
Structural Characteristics
8U height standard 19-inch rack integrated chassis, front panel graphical touch screen and physical navigation keypad, rear dual redundant power supply input terminals, upper rear fieldbus and analog I/O wiring terminal strip, internal modular signal conditioning sub-assemblies serviceable without full chassis disassembly
Working Principle
Universal analog input channels receive continuous process signals from field transmitters, converted to digital process variable values via high-resolution ADC circuits. Each independent PID loop executes closed-loop regulation calculations against user-programmed setpoint values, generating corresponding analog or relay output signals to manipulate process control valves and actuators. HART fieldbus communication interface enables bidirectional digital data exchange with smart transmitters, uploading sensor diagnostic data and downloading remote calibration parameters to field instruments. All alarm events and process trend data are continuously logged to onboard non-volatile flash memory for plant historical performance analysis.
Advantage Highlights
- 15 independent PID loops integrated within single rack chassis reduces DCS subsystem hardware footprint
- Native dual HART/FOUNDATION Fieldbus communication compatible with all Honeywell smart process transmitters
- Redundant dual mains power input eliminates single power supply point of failure
- High precision 18-bit analog sampling ensures accurate low-range flow and pressure measurement
- Integrated graphical touch display eliminates requirement for separate local HMI unit
Applicable Industries
Petrochemical refining plant, natural gas processing facility, chemical batch reaction production, combined cycle power plant auxiliary process control, oil & gas pipeline metering stations
Installation Requirements
- Mount unit into standard 19-inch instrument rack with four front panel mounting fasteners
- Install forced-air rack cooling fan to maintain chassis internal temperature below 60°C at full loop load
- All field analog signal wiring uses shielded twisted pair cable with single-point chassis shield grounding
- Dual redundant power supply inputs connected to separate isolated factory mains distribution circuits
Usage Precautions
- Conduct full multi-loop calibration every 24 months to maintain 18-bit sampling measurement precision
- Avoid mounting chassis adjacent to high-power variable frequency drive equipment to minimize electromagnetic interference
- Back up process control loop configuration parameters to external storage before chassis maintenance power-off
- Immediately replace faulty internal signal conditioning sub-modules upon persistent single-channel measurement deviation faults
