Honeywell CC-TAON11

Description

Technical Specifications:

• Model Number: CC-TAON11

• Part Number: 51306521-175

• Product Type: Analog Output Module

• System Compatibility: Honeywell C300 Controller

• Output Channels: 8 analog output channels

• Output Range: 0-10V or 4-20mA

• DAC Resolution: 16-bit for high precision control

• Operating Voltage: 12 to 24 VDC

• Output Current: Up to 20 mA

• HART Compatibility: Communicates with HART-enabled devices

• Hazardous Location Rating: Suitable for Division 2 non-incendive/Zone applications

• Material: Premium materials ensuring durability and consistent performance

Functional Features:

• Precise Control: 16-bit DAC resolution for high-precision analog output

• Flexible Output Ranges: Supports both 0-10V and 4-20mA for compatibility with various control systems

• HART Communication: Enables communication with HART-enabled field devices

• Wide Operating Voltage: 12 to 24 VDC for compatibility across different power sources

• Integrated Termination: Combines I/O and field termination in same area

Performance Parameters:

• DAC Resolution: 16-bit

• Output Current Capability: Up to 20 mA

Material Composition: Premium industrial-grade materials ensuring durability and consistent performance throughout lifecycle.

Structural Features: Combines input/output modules and field terminations in the same physical area.

Working Principle: The CC-TAON11 receives digital control signals from the C300 controller, converts them to analog output signals using a 16-bit DAC, and transmits the signals to field devices such as valves, motors, and actuators.

Advantages and Highlights:

• High-precision 16-bit DAC for accurate process control

• Flexible output range selection (0-10V or 4-20mA)

• HART compatibility for advanced device communication

• Suitable for hazardous (Division 2) locations

Applicable Industries:

• Process control systems

• Distributed Control Systems (DCS)

• Industrial automation

Model Series: Honeywell Experion PKS Series C

Installation Requirements:

• Designed for use with C300 Controller

• Requires compatible IOTA assembly

• Proper field wiring termination per guidelines

Usage Precautions:

• Verify output range (0-10V or 4-20mA) matches field device requirements

• Do not exceed maximum output current of 20 mA

• Observe hazardous location ratings for Division 2 installations

• Ensure proper grounding for signal integrity
