HONEYWELL CC-PCF901

Description

Technical Specifications:

• Product Model: CC-PCF901 (51405047-176)

• Manufacturer: Honeywell

• Product Type: Control Firewall Module

• Ports: 9 FTE ports (8 ports + 1 uplink port)

• Network Interfaces: Ethernet, RS-485

• Supported Protocols: Modbus RTU, BACnet

• Maximum Network Connections: 32

• Supply Rating: 0.112A @ 24VDC

• Operating Temperature: -40°C to +85°C

• Protection Rating: IP65 / IP67

• Dimensions: 89 mm × 35 mm × 25 mm

• Weight: 0.15 kg

• Housing Material: Metal

Functional Features:

• FTE Cable Distribution: Efficiently distributes FTE cables to multiple Series C FIMs

• Network Security: Deep packet inspection identifies and blocks malicious code, abnormal traffic, and unauthorized commands

• In-Cabinet Network Distribution: Provides FTE distribution to in-cabinet network nodes (C300 Controllers and Series C Modules)

• IOTA Mounting: Module mounts on CF9 Input/Output Termination Assembly (IOTA)

Performance Parameters:

• Port Count: 9 FTE ports

• Supply Current: 0.112A @ 24VDC

• Temperature Range: -40°C to +85°C

Material Composition:

• Housing: Metal construction

• Protection: IP65/IP67 rated for harsh environments

Structural Features:

• Compact form factor: 89 × 35 × 25 mm

• Lightweight: 0.15 kg for easy installation

• Mounts on CF9 IOTA

• Series C form factor compatibility

Working Principle:
The CC-PCF901 receives FTE network traffic from the control system, performs deep packet inspection to identify and block unauthorized or malicious traffic, and distributes validated FTE communications to multiple Series C FIMs and in-cabinet network nodes. It enforces security policies between the control system internal network and external networks, ensuring only compliant communications pass through.

Advantages & Strengths:

• Dual functionality: FTE distribution + network security in single module

• Deep packet inspection provides industrial-grade cybersecurity

• Wide operating temperature range supports extreme environments

• High protection rating (IP65/IP67) for durability

• Compact size enables space-efficient cabinet installation

Applicable Industries:

• Commercial Buildings: Firewall control and management for building safety

• Industrial Facilities: Firewall control protecting critical equipment and personnel

• Data Centers: Firewall management protecting sensitive data

• Process Industries: Control system network segmentation and security

Model Series: Honeywell CC-PCF Series / Experion PKS Series C

Installation Requirements:

• Mounts on CF9 Input/Output Termination Assembly (IOTA)

• Standard Series C rack installation

• Proper network cable connections to FTE ports

• Adequate ventilation for thermal management

Usage Precautions:

• Monitor security event logs for异常 traffic alerts

• Regular firmware updates for security patch management

• Verify proper FTE cable termination

• Ensure power supply meets 0.112A @ 24VDC requirement
