Product Short Description
- Product Name: 900 Series Analog Signal Module
- Product Brief: High-precision analog input module of Honeywell 900 DCS system, used for continuous analog signal collection of temperature, pressure, flow and other process parameters in industrial sites.
- Technical Specifications: Signal type: Standard 4-20 mA / 1-5 V analog signal; Channel configuration: Single-channel high-precision acquisition; Resolution: 16-bit; Support signal range automatic adaptation.
Description
- Functional Features: High-precision collection of industrial analog process signals; Signal amplification, isolation and linear correction; Transmit data to DCS main controller; Built-in signal fault diagnosis function.
- Performance Parameters: Working temperature: -20°C ~ 70°C; Measurement accuracy: ±0.1% FS; Response speed: ≤ 20 ms; Isolation strength: 2000 VAC; Humidity adaptability: 5% ~ 95% non-condensing.
- Material Composition: Outer casing: V0 grade flame-retardant engineering plastic; Internal circuit: Industrial grade high-precision operational amplifier and isolation chip; Wiring terminal: Tin-plated copper alloy; PCB: High stability FR-4 substrate.
- Structural Characteristics: DIN rail modular installation; Plug-in type overall structure; Integrated wiring terminal row; Compact internal circuit layout, anti-vibration and anti-dust design.
- Working Principle: Receive analog weak signals output by field transmitters and sensors, complete signal isolation, amplification and digital conversion inside the module, and upload standardized digital data to the upper computer for process monitoring and control.
- Advantages & Highlights: Ultra-high measurement accuracy; Strong anti-interference ability for industrial field; Complete fault self-diagnosis function; Compatible with all Honeywell 900 series main units; Stable long-term operation.
- Applicable Industries: Petrochemical, Thermal power, Metallurgy, Pharmaceutical, Environmental protection, Industrial process automation.
- Model Series: Honeywell 900 DCS Analog Acquisition Module Series
- Installation Requirements: Install in sealed industrial control cabinet; Adopt shielded cable for signal wiring; Separate signal cable and power cable; Install on standard DIN mounting rail.
- Usage Notes: Do not apply over-range signal input; Keep the cabinet ventilated and dust-proof; Regularly calibrate signal accuracy; Cut off power before disassembly and wiring.
