Product Short Description
- Product Name: Honeywell Analog Output Module
- Product Overview: Analog output module for Honeywell distributed control system, used to convert digital control commands from main controller into standard analog signals to drive on-site regulating actuators.
- Model Series: Honeywell Analog Output Module Series
Description
- Technical Specifications:
- Output Signal: 4-20 mA standard analog current signal
- Power Supply: 24 VDC ±10%
- Output Accuracy: ±0.15% full scale
- Operating Temperature: 0 °C ~ +60 °C
- Load Capacity: Support standard industrial actuator load
- Functional Features: Digital-to-analog conversion, analog signal output, output over-current protection, load short-circuit protection, output amplitude adjustment, channel status monitoring.
- Performance Parameters: High output precision, good signal linearity, stable load driving capability, low temperature drift, strong anti-electromagnetic interference.
- Material Composition: Flame-retardant insulated housing, high-precision D/A conversion chip, heat-resistant power components, tin-plated wiring terminals, internal heat dissipation structure.
- Structural Characteristics: Standard rack-mount modular structure, front panel with working status indicators, independent output channel terminals, integrated overload protection structure.
- Working Principle: Receive digital control instructions sent by DCS main controller, complete digital-to-analog conversion through internal D/A circuit, output standard 4-20 mA analog signals to on-site regulating valves, frequency converters and other actuators to realize process regulation.
- Advantages & Highlights: Precise analog output, reliable load driving, comprehensive protection functions, good environmental adaptability, seamless compatibility with Honeywell control system.
- Applicable Industries: Petrochemical, thermal power, chemical fiber, water treatment, pharmaceutical industry, industrial process regulation system.
- Installation Requirements: Mount on standard industrial rack; reserve heat dissipation space around module; match output channels with on-site actuators one by one; ensure reliable grounding.
- Usage Notes: Do not exceed maximum load range of output channel; avoid short circuit of output terminals; perform regular signal calibration; power off system during maintenance and replacement.
