Product Short Description
Product Name
High-Speed Digital Input Module, 24 V DC, 16-Channel (Experion PKS / TDC-type I/O)
Product Introduction
The 51304511-200 is a 16-channel high-speed 24 V DC digital input module used in Honeywell Experion PKS and compatible DCS/PLC I/O families. It captures discrete contact states and high-frequency pulse trains for counting and speed measurement.
Description
Technical Specifications
- Input Voltage: 24 V DC (operating range 18-30 V DC)
- Channels: 16 isolated digital inputs
- Input Delay: 0.1 ms to 10 s (configurable)
- Count Frequency: Up to 1 kHz
- Isolation: Optical, 2500 V AC
- Power Consumption: 2.5 W
- Operating Temperature: -40 to 85 °C
- Humidity: 5 to 95% non-condensing
- Wire Size: 0.2 to 2.5 mm²
- Mounting: DIN rail / rack-mounted I/O carrier
Functional Features
- High-speed pulse counting per channel
- Optical isolation against ground loops and electrical noise
- Field-side wiring diagnostics
- Configurable debounce and alarm delay
Application Scenarios
Flow totalization from pulse meters, tachometer feedback, fast interlock sensing, and discrete status acquisition in power, oil and gas, and batch process plants.
Structural Characteristics
Standard Honeywell I/O module form factor with plug-in rear connector and field-terminal block interface. LED per channel for input state.
Working Principle
Each input channel optically isolates the 24 V field signal, conditions it through a configurable filter, and latches state or edge counts into the module FPGA/ASIC. The controller reads the latched data over the I/O bus.
Installation Requirements
Seat in the designated Honeywell I/O carrier slot. Supply 24 V DC field power to the terminal block. Ground the shield correctly and respect wire gauge limits.
Usage Precautions
Set input delay appropriately for pulse applications; excessive debounce will miss counts. Confirm isolation rating before mixing voltage sources. Avoid hot removal unless the carrier explicitly supports it.
Reviews
There are no reviews yet.
