Description
-
Technical Specifications:
-
Ethernet Standard: IEEE 802.3U (Fast Ethernet)
-
Transmission Speed: 10/100 Mbps
-
Physical Layer: 100BASE-TX (Twisted Pair)
-
Connector: 1 × RJ45
-
Connection Capacity: 64 nodes
-
Protocols: TCP-IP, UDP-IP, Ethernet/IP, CSMA/CD
-
Current Consumption: 410 mA
-
Conformal Coating: Yes (CAT5)
-
Configuration Software: SoftMaster-NM (IP address setting, DNS, gateway); DHCP for dynamic IP
-
Compatibility: MasterLogic 200 Series CPU units
-
-
Key Features:
-
Integrates MasterLogic-200 PLC into Experion network
-
Suitable for fast logic, sequential and batch control applications
-
Compact yet powerful and versatile
-
Cost-effective communication solution
-
-
Application: Industrial Ethernet communication for logic-interlock-sequence batch control in the Experion network.
-
Installation Requirements: Install into a compatible MasterLogic 200 CPU rack; terminate Ethernet cable with RJ45.
-
Usage Notes: IP address, DNS, and gateway must be configured via SoftMaster-NM.
