Fieldbus Interface: MPI/PROFIBUS (up to 12 Mbps) for direct S7-300/S7-400 connection
-
Serial Interface: RS-232 / RS-485 (RJ45 socket)
-
USB: USB 2.0 host for firmware update & local configuration
-
I/O Manager: Can read & store up to 256 PLC variables for remote monitoring
-
Redundancy: Multi-WAN management (e.g., WAN + analog dial-up failover)
-
Power Supply: 24 VDC (10–30 VDC operating range)
-
Current Draw: Max. 500 mA @ 24 VDC
-
Operating Temperature: 0 °C to +50 °C
-
Humidity: 95 % r.H. non-condensing
-
Protection Rating: IP20
-
Certifications: CE, RoHS, REACH
-
Dimensions: 125 × 40 × 128 mm (D × W × H), ~300 g
-
Core Features:
-
Secure remote access to PLC, HMI, IP cameras
-
Free VPN routing via myREX24
-
Integrated firewall — only authenticated users gain access
-
Serial-over-IP for incorporating legacy serial devices into remote maintenance
-
Application: Remote servicing & tele-maintenance of Siemens-controlled machinery, industrial IoT gateway
-
Installation: DIN-rail mount inside control cabinet (IP20 — not for direct environmental exposure); configure VPN via myREX24 V2 portal.
