Product Short Description
The GE VMIVME-7452 is a 6U single-slot VMEbus storage module designed for embedded industrial systems. It provides flexible, high-reliability mass storage options—integrating a 3.5-inch hard disk drive (HDD), a 3.5-inch floppy disk drive (FDD), or both, with an optional flash memory upgrade. As a passive VMEbus board, it draws power directly from the VMEbus backplane, eliminating the need for external power supplies. It serves as a dedicated storage expansion for GE VMIC VMEbus single-board computers (SBCs) in critical industrial control and data logging applications.
Description
Technical Specifications
- Form Factor: 6U single-height VMEbus module (1 slot)
- Storage Configuration: Supports 1×3.5-inch HDD + 1×3.5-inch FDD; optional flash memory drive
- HDD Capacity (Standard): 20 GB (IDE interface)
- FDD Specification: 1.44 MB, 3.5-inch IDE floppy drive
- VMEbus Interface: Passive, connects to P2 user-defined pins (power/ground only)
- Power Requirements: +5 V DC from VMEbus; 1.2 A typical
- Operating Temperature: -40°C to +85°C (-40°F to +185°F)
- Storage Temperature: -55°C to +125°C (-67°F to +257°F)
- Humidity: 5%–95% (non-condensing)
- Dimensions (H×W×D): 233 mm × 160 mm × 40 mm (9.2 in × 6.3 in × 1.6 in)
- Weight: 1.2 kg (2.6 lbs)
- Compliance: CE marked; meets IEC 61000-6-2 for industrial EMC
Key Features
- Dual Storage Integration: Combines HDD and FDD in one slot, optimizing space in VMEbus chassis.
- Passive VMEbus Design: No onboard power regulation; uses VMEbus power for simplified integration and reduced heat.
- Flexible Media Support: Compatible with IDE HDDs, FDDs, and solid-state flash drives for legacy and modern storage needs.
- Wide Environmental Tolerance: Operates reliably in extreme temperatures and humidity for harsh industrial environments.
- VMEbus Compatibility: Seamlessly integrates with all standard 6U VMEbus backplanes and GE VMIC SBCs (e.g., VMIVME-7750).
- High Shock/Vibration Resistance: Ruggedized PCB and drive mounting for industrial shock and vibration conditions.
- Hot-Swap Capability: Supports hot-swap installation/removal in compatible VMEbus chassis for minimal downtime.
- Legacy System Longevity: Preserves access to legacy floppy-based software/data while supporting modern HDD/flash storage.
Application Scenarios
- Industrial Automation: Provides local storage for VMEbus-based PLCs and control systems in manufacturing and assembly lines.
- Process Control: Deployed in chemical, petrochemical, and water treatment plants for data logging, recipe storage, and system backups.
- Power Generation: Used in thermal, hydroelectric, and nuclear power plants for storing control logic, historical data, and firmware.
- Aerospace & Defense: Integrated into ruggedized VMEbus systems for data storage in avionics, ground control, and military applications.
- Transportation: Applied in railway and mass transit systems for onboard data logging, system configuration, and maintenance records.
- Legacy System Upgrades: Enhances aging VMEbus systems with modern storage while maintaining compatibility with legacy floppy-based media.
Functional Overview
The VMIVME-7452 functions as a dedicated storage expansion for VMEbus embedded systems. It connects to the VMEbus backplane via the P2 connector, drawing +5 V power and providing direct access to HDD, FDD, or flash media. The passive design ensures minimal power consumption and heat generation, while the rugged construction withstands harsh industrial conditions. By combining legacy floppy support with modern HDD/flash options, it enables seamless data storage, system backups, and legacy media access for VMEbus-based control and monitoring systems.
