Product Short Description
The IS220PRTDH1A is a high-precision Resistance Temperature Detector (RTD) input pack engineered exclusively for the GE Mark VIe Speedtronic turbine control and distributed automation platforms. It serves as the dedicated interface between RTD sensors (Pt100, Pt500, Cu100) and the Mark VIe IONet Ethernet network, delivering accurate, high-resolution temperature data acquisition for safety-critical industrial processes. Designed for both simplex and redundant system architectures, it integrates 8 isolated input channels, advanced signal conditioning, and comprehensive diagnostics to ensure stable, reliable temperature monitoring in extreme industrial environments.
Description
Technical Specifications
- Input Channels: 8 independent RTD input channels
- Supported RTD Types: Pt100 (100 Ω), Pt500 (500 Ω), Cu100 (100 Ω)
- Temperature Measurement Range: -200°C to +800°C (-328°F to +1472°F)
- Resolution: 14-bit analog-to-digital converter (ADC)
- Accuracy: ±0.1°C full scale (FS)
- Lead Resistance Compensation: Supports 3-wire and 4-wire RTD connections; max 15 Ω lead resistance per channel
- Sampling Rate: 100 Hz per channel
- Isolation: 2500 V AC channel-to-channel and channel-to-backplane isolation (1 minute)
- Communication: Dual RJ45 IONet (10/100 Mbps Ethernet)
- Processor: Shared 667 MHz Freescale PowerQUICC II Pro (system-wide I/O pack processor)
- Power Supply: 22.5–28.6 V DC (24 V DC nominal, rack-powered)
- Power Consumption: Typical 4 W, maximum 6 W
- Operating Temperature: -40°C to +70°C (-40°F to +158°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Humidity: 10%–95% (non-condensing)
- Dimensions (L×W×H): 165 mm × 102 mm × 88 mm (6.5 in × 4.0 in × 3.5 in)
- Weight: 0.7 kg (1.54 lbs)
- Connectors: DC-37 pin (terminal board interface), 3-pin power input
- LED Indicators: Power, ATTN (attention), Ethernet Link/Activity (2 ports)
- Certifications: CE (EN 61000-6-2), UL 508, CSA C22.2 No.14-13, ATEX Zone 2 (IIC), RoHS
- Conformal Coating: Full PCB conformal coating for harsh environment protection
Key Features
- 8-Channel High-Density RTD Monitoring: Simultaneously acquires temperature data from 8 RTD sensors, supporting multi-point temperature monitoring for turbines, boilers, and process equipment.
- Multi-RTD Type Compatibility: Natively supports Pt100, Pt500, and Cu100 RTD sensors, accommodating diverse industrial temperature measurement requirements.
- 3/4-Wire Lead Resistance Compensation: Eliminates measurement errors caused by long sensor cables, ensuring accurate temperature readings even in remote field installations.
- 2500 V AC High Electrical Isolation: Provides robust channel-to-channel and channel-to-backplane isolation, preventing electrical noise, cross-talk, and ground loops from corrupting temperature data.
- Dual Redundant IONet Communication: Equipped with dual Ethernet ports for redundant network connectivity, eliminating single points of failure and ensuring uninterrupted data transmission to the Mark VIe controller.
- ±0.1°C High Precision & 100 Hz Fast Sampling: Delivers precise temperature measurements and rapid detection of temperature transients, critical for real-time turbine health monitoring and process control.
- Comprehensive Sensor & Channel Diagnostics: Detects RTD open/short circuits, lead resistance faults, and signal anomalies; front-panel LEDs provide immediate visual status for power, communication, and system alerts.
- Harsh Environment Durability: Features full conformal coating, vibration-resistant construction, and wide temperature tolerance (-40°C to +70°C), ensuring reliable operation in industrial environments with extreme temperatures, humidity, and electrical interference.
- Seamless Terminal Board Integration: Interfaces with IS200TRTDH2D/IS200SRTDH1A/IS200SRTDH2A terminal boards for simplified field wiring, signal conditioning, and surge protection.
Application Scenarios
- Power Generation Plants: Deployed in gas turbine, steam turbine, and combined-cycle power plants for critical monitoring of bearing temperature, exhaust gas temperature, stator winding temperature, and boiler water/steam temperature; enables predictive maintenance and protects against overheating-related equipment failure.
- Oil & Gas Industry: Used in refineries, compressor stations, and offshore platforms to monitor turbine-driven compressors, process heaters, and reactor temperatures; supports safe, efficient operation of high-temperature process equipment.
- Industrial Cogeneration: Applied in chemical plants, steel mills, and pulp/paper facilities with on-site turbine-based power generation; monitors furnace, boiler, and process temperatures to optimize energy efficiency and meet emissions standards.
- Process Industries: Utilized in water treatment, pharmaceuticals, and food/beverage plants for precise temperature control of reactors, sterilizers, and production lines; ensures consistent product quality and regulatory compliance.
- Hazardous Locations: Certified for ATEX Zone 2 (IIC) hazardous areas when paired with approved terminal boards, enabling safe temperature monitoring in explosive gas environments.
Functional Overview
The IS220PRTDH1A functions as the dedicated temperature data acquisition hub within the Mark VIe system. It receives resistance signals from RTD sensors via terminal boards, converts them to high-resolution digital temperature values using a 14-bit ADC, and compensates for lead resistance to ensure accuracy. Processed temperature data is transmitted to the main Mark VIe controller via dual redundant IONet ports for real-time monitoring, alarm generation, and control actions. Onboard diagnostics continuously monitor sensor and channel health, while LED indicators provide immediate operational visibility. The pack’s compact, rugged design enables easy installation in standard Mark VIe I/O cabinets and reliable operation in the harshest industrial conditions.
