Product Short Description
Product Name: GE Fanuc A06B-1501-B105 Servo Amplifier Unit
Product Series: GE Fanuc A06B Series Servo Drive Amplifier Module
Product Brief: Special servo amplifier for industrial servo control system, used to drive and control GE Fanuc servo motors, realize power amplification, signal processing and motion control.
Description
- Input Power: AC 200 ~ 230 V, 50 / 60 Hz
- Output Type: Three-phase AC servo power output
- Control Signal Interface: Standard CNC system signal interface
- Overload Protection Threshold: 150% rated current (short-time tolerance)
- Protection Function Configuration: Overvoltage, undervoltage, overcurrent, overheat protection
Functional Features: Receives position and speed commands from CNC system; outputs driving power to servo motor; real-time collection of motor operating parameters; fault self-diagnosis and code display; closed-loop servo control.
Performance Parameters: Operating temperature: 0 °C ~ +55 °C; Storage temperature: -20 °C ~ +75 °C; Working humidity: 10% ~ 90% RH (non-condensing); Heat dissipation mode: Forced air cooling.
Material Composition: Main cabinet: Cold-rolled steel plate; Power module: IGBT power semiconductor module; Control board: Industrial multilayer PCB; Heat sink: High thermal conductivity aluminum alloy; Wiring terminal: Flame-retardant engineering plastic + copper terminal.
Structural Characteristics: Vertical cabinet installation structure; internal partition layout for power circuit and control circuit; front panel with fault code display window and indicator lights; built-in cooling fan and air duct.
Working Principle: Converts AC input power into adjustable frequency and adjustable voltage AC power via rectifier and inverter circuit; receives control commands from upper computer, adjusts output power in real time, and cooperates with motor encoder feedback to complete high-precision servo control.
Advantages & Highlights: High power conversion efficiency; fast response speed; complete fault diagnosis function; strong anti-interference ability; fully compatible with matching GE servo motors and CNC systems.
Applicable Industries: CNC machine tool industry, automated production equipment, precision processing equipment, industrial robot control system.
Installation Requirements: Vertical installation on equipment rack; keep unobstructed air inlet and outlet for heat dissipation; power wiring and signal wiring are routed separately; ground wire must be connected reliably.
Usage Notes: Strictly prohibit overloading operation; regularly clean cooling fan and heat sink dust; cut off power before disassembly and maintenance; stop operation immediately when fault code appears and troubleshoot.
