Product Short Description
Product Brief
High-speed 4-axis PCIe x4 bus motion control card under Galil DMC-9900 series, industrial PC plug-in high-precision motion controller optimized for ultra-fast positioning and high-frequency encoder feedback applications; supports ±10 V analog servo and differential pulse stepper output, high-speed 32-bit position capture, dedicated for ultra-precision laser processing, semiconductor wafer handling and micro-positioning stages.
Description
Technical Specifications
- Model Series: Galil DMC-9900 PCI Express High-Speed Motion Control Card Series
- Controllable Axis Count: 4 independent high-precision servo/stepper axes
- Host Bus Interface: PCI Express x4 Gen 2 high-speed bus
- Axis Output Modes: 16-bit ±10 V DAC analog servo output, differential pulse+direction stepper output
- Encoder Feedback Input: 4 differential A/B/Z phase encoder channels, max 32 MHz input frequency
- Servo Control Loop Update Rate: 31 µs ultra-fast synchronous 4-axis PID calculation
- Digital I/O Channels: 12 high-speed optically isolated DI, 12 high-speed optically isolated DO
- High-Speed Position Latch Hardware: Per-axis dual independent position capture trigger circuits
- Onboard Program Memory: 1 MB high-speed non-volatile flash memory for motion algorithm storage
- Position Counter Resolution: 32-bit floating-point high-precision position register per axis
- Host Communication Throughput: 400 MB/s PCIe bus maximum data transfer rate
- Rated Power Supply: 12 VDC PCIe slot host power supply
- Operating Temperature Range: 0 °C ~ +70 °C
- Storage Temperature Range: -40 °C ~ +85 °C
- Relative Humidity Tolerance: 20%–95% non-condensing
- PCB Form Factor: Standard full-length PCIe expansion card
- Net Weight: 210 g
Functional Features
- 31 µs ultra-fast 4-axis synchronous PID control loop for ultra-high response precision micro-positioning applications
- PCIe x4 Gen2 high-speed bus delivers 400 MB/s bidirectional data throughput between card and industrial PC host
- Per-axis dual independent hardware position latch circuits for sub-micron precision registration cutting and laser triggering
- Full advanced motion algorithm library: ultra-smooth jerk-limited trajectory generation, linear/circular interpolation, electronic cam, gantry synchronization
- Fully optically isolated high-speed digital I/O channels with nanosecond-level hardware trigger response
- 32-bit floating-point position registers eliminate integer calculation rounding error for micro-positioning stages
- Full GalilSuite cross-platform software support for Windows and Linux semiconductor industrial PC development
Performance Parameters
- Maximum Differential Stepper Pulse Output Frequency: 10 MHz per axis
- Encoder Maximum Input Frequency: 32 MHz high-speed differential line driver encoder signals
- Full 4-Axis PID Loop Latency: 31 µs synchronous update cycle
- Analog DAC Output Resolution: 16-bit low-drift servo control signal
- Hardware I/O Trigger Response Delay: ≤ 0.2 µs high-speed capture signal response
- ESD Surge Withstand Capacity: 4 kV contact discharge on all field I/O and encoder terminals
- Vibration Resistance: 10 Hz – 150 Hz, 1 g continuous cabinet vibration
Material Composition
- Main Circuit Substrate: FR4 ultra-low crosstalk multi-layer industrial PCIe PCB with controlled impedance routing
- PCIe Bus Connector: Gold-plated high-speed x4 PCIe edge finger connector with impedance matching
- Encoder Interface Chips: 32 MHz high-speed differential line receiver isolation ICs
- Analog DAC Components: Ultra-low temperature drift 16-bit industrial digital-to-analog converters
- Optocoupler Isolation Array: Nanosecond high-speed wide-temperature opto-isolators for all field I/O circuits
- PCIe Bracket: Thickened cold-rolled steel anti-corrosion mounting bracket with dual D-Sub wiring cutouts
Structural Characteristics
- Standard full-length PCIe x4 plug-in card form factor compatible with all industrial PC PCIe Gen2 expansion slots
- Strictly partitioned PCB layout zones: PCIe high-speed bus circuit, analog servo output circuit, high-speed encoder I/O circuit to eliminate signal crosstalk
- Dual D-Sub multi-pin external connectors mounted on PCIe rear steel bracket for centralized field wiring access
- Large-area copper passive heat dissipation pads on PCB for core high-speed motion processor thermal management
- Multi-layer electromagnetic isolation barrier between PC host PCIe bus circuit and field high-frequency signal circuits
- Standard mounting screw hole on steel bracket for rigid fixation inside industrial PC chassis
Working Principle
High-speed PCIe x4 bus transmits ultra-precision motion trajectory commands and parameter data from semiconductor industrial PC host to DMC-9940 onboard 64-bit RISC motion processor. The processor executes 31 µs ultra-fast synchronous PID closed-loop control algorithms for 4 independent axes, generates high-frequency differential pulse or 16-bit ±10 V analog servo drive commands output to external high-precision servo amplifiers. 32 MHz differential encoder position feedback signals from micro-positioning stage motors transmit back to card encoder input channels; 32-bit floating-point position registers calculate sub-micron axis position error for continuous high-speed PID correction. Per-axis dual hardware position latch circuits capture encoder position values at nanosecond trigger signal arrival for laser firing and semiconductor wafer alignment registration. Optically isolated high-speed digital DI channels receive micro-limit, home and laser trigger signals to execute instant motion safety interlock logic; isolated DO channels output high-speed actuator trigger signals to field precision equipment. All motion algorithms and tuning parameters are stored in 1 MB onboard flash memory for power-off permanent retention.
