Product Name: Galil DMC-4143 4-Axis Standalone Motion Controller
Product Overview: The DMC-4143 is a standalone motion controller from the DMC-41×3 series, offering cost-effective 4-axis motion control for servo and stepper motors. It provides high-speed communication and advanced motion capabilities in a compact, independent package.
Description
Technical Specifications:
- Number of Axes: 4
- Encoder Inputs: Differential, Quadrature, A, /A, B, /B, Z, /Z
- Encoder Feedback: 15 MHz servo encoder feedback
- Step Motor Command: 3 MHz (pulse + direction)
- Analog Inputs: 8 channels, 12-bit
- Digital I/O: 16 in, 16 out
- Communication: Ethernet 10/100Base-T, USB (main), RS-232 (aux)
- Power Supply: 20–80 V DC
- Current: 3 A per phase continuous, 6 A peak
- Dimensions: 7.875″ × 5.00″ × 1.50″ (4-axis version)
- Weight: 1.8 lbs
Functional Features:
- Controls 1–8 axes of servo motors, stepper motors, or mixed configurations
- Advanced PID compensation with velocity feedforward, acceleration feedforward, integral limiting, notch filter, low-pass filter
- Multiple motion modes: JOG, PTP positioning, position following, linear/circular/helical interpolation, electronic gear, gantry sync, electronic cam, contouring, teaching, elliptical scaling, corner deceleration, infinite segment feed, proportional control
- Simultaneous execution of 8 application programs
- Dual encoder input, home input, forward/reverse limit inputs
- High-speed position latch and output compare
- Non-volatile memory for applications, variables, and arrays
- User program storage: 4000×80; Variables: 510; Array space: 24000
- Optional stepper or servo motor drivers can be attached
- Library support for Windows, QNX, and Linux
Structural Characteristics: Standalone metal enclosure, compact form factor (7.875″ × 5.00″ × 1.50″ for 4-axis).
Working Principle: The controller executes motion programs from non-volatile memory, processes quadrature encoder feedback at 15 MHz, performs PID computation with feedforward, and outputs ±10 V analog commands or 3 MHz step/direction pulses to drive amplifiers.
Application Scenarios: Industrial automation, robotics, motion control systems, and medical device manufacturing where space is at a premium.
Installation Requirements:
- 20–80 V DC power supply
- Ethernet/USB/RS-232 communication cabling
- Panel or DIN-rail mount in control cabinet
- Connect via optically isolated I/O and analog interfaces
Usage Notes:
- Standalone operation or PC-controlled via Ethernet/USB
- Use Galil Design Kit (GDK) for programming and tuning
- Supports simultaneous execution of up to 8 application programs
- 4-axis version dimensions: 8.1″ × 7.25″ × 1.5″; 5–8 axis version: 11.5″ × 7.25″ × 1.5″
