Product Short Description
Product Name: Galil DMC-1832 16-Axis Motion Controller
Product Overview: The Galil DMC-1832 is a next-generation, high-performance standalone or PC-connected motion controller. It features a compact metal housing and can optionally integrate multi-axis drive amplifiers. It controls up to 16 axes of servo or step motors with exceptional command processing speed.
Description
Technical Specifications:
- Processor: 32-bit RISC processor
- Memory: 2 MB Flash, 1 MB SRAM
- Maximum Axes Controlled: 16
- Encoder Input Frequency: up to 22 MHz
- Servo Update Rate: up to 32 kHz
- Command Processing Speed: 40 microseconds (10× faster than previous generation)
- Instructions per Axis per Cycle: up to 256
- Power Supply: 20–80 V DC single supply
- Communication: Ethernet 10/100Base-T, RS-232
- I/O: Optically isolated I/O, high-power outputs for brakes or relays, analog inputs for analog sensors
Functional Features:
- Controls servo and stepper motors (mixed configurations)
- High-speed encoder feedback processing (22 MHz)
- Advanced PID compensation with velocity and acceleration feedforward, integral limiting, notch filter, and low-pass filter
- Multiple motion modes: JOG, PTP positioning, position following, linear/circular/helical interpolation, electronic gear, gantry synchronization, electronic cam, contouring, teaching, elliptical scaling, corner deceleration, infinite segment feed, proportional control
- Simultaneous execution of 8 application programs
- Non-volatile memory for application storage, variables, and arrays
- Library support for Windows, QNX, and Linux communication
Structural Characteristics: Compact metal enclosure designed for panel mounting or integration into control cabinets.
Working Principle: The RISC processor executes motion programs stored in non-volatile memory, reads encoder feedback at up to 22 MHz, computes PID with feedforward at up to 32 kHz servo update rate, and outputs ±10 V analog commands or step/direction pulses to drive amplifiers.
Application Scenarios: Precision automation, robotics, multi-axis machine control, semiconductor equipment, CNC machinery, and high-speed packaging lines.
Installation Requirements:
- 20–80 V DC power supply
- Ethernet or RS-232 communication cabling
- Mount in control panel or cabinet with adequate ventilation
- Connect via optically isolated I/O and analog interfaces
Usage Notes:
- Can run standalone with stored programs or be PC-controlled
- Supports Galil Design Kit (GDK) for programming and tuning
- High-speed command processing at 40 µs minimizes latency
