Product Short Description

  • Product Name: 8-Channel Analog Output Module
  • Product Overview: A high-precision, isolated analog output module for the Foxboro I/A Series, providing control signals to field actuators and transmitters.
  • Technical Specifications:
    • Channels: 8 isolated analog outputs
Share on Facebook
Share on Twitter
Email This Product
Foxboro FXAOM01AD 8-Channel Analog Output Module
Foxboro FXAOM01AD 8-Channel Analog Output Module - Image 2

Description

    • Output Ranges: 4-20mA / 0-20mA (software configurable)
    • Resolution: 12-bit
    • Accuracy: ±0.1% Full Scale (FS)
    • Update Time: 12ms per channel
    • Load Resistance: 0-550Ω
    • Isolation: Channel-to-channel and system isolation
  • Key Features:
    • High Precision: Delivers accurate, repeatable analog control signals.
    • Redundancy Support: Compatible with redundant system configurations for fault tolerance.
    • Diagnostics: Built-in fault detection for open/short circuits and over-range conditions.
  • Applications:
    • Control of valves, actuators, and variable-speed drives in process industries.
    • Analog signal interfacing for temperature, pressure, and flow control loops.
