PR6423 000-101-CN belongs to PR6423 miniature probe series with 8mm sensing head diameter and M8×1 miniature mounting thread. Suffix code 000 represents standard ±2mm linear measuring range; suffix code 101 stands for medium 101mm probe body length; suffix code -CN marks China localized calibrated version, factory pre-calibrated for domestic 45# steel and 42CrMo4 steel shaft targets, compatible with domestic standard turbomachinery vibration monitoring systems. This probe is designed for small and medium-sized rotating equipment bearing housings with medium depth installation space, must be matched with CON021 signal conditioner to form complete measuring system.
Description
Technical & Performance Specifications
- Probe Core Parameters
- Linear measuring range: ±2mm standard general range (suffix code 000)
- Probe total body length: medium 101mm (suffix code 101)
- Probe head diameter: 8mm miniature size
- Standard integrated shielded coaxial cable length: 5m
- Matched system sensitivity: 8 V/mm
- Full system linearity error: ≤±1% full scale
- Frequency response bandwidth: DC ~ 10kHz
- Probe operating temperature: -40°C ~ +120°C
- Protection grade of probe body: IP66
- Standard measuring target: domestic ferromagnetic 45# steel and 42CrMo4 alloy steel (China localized -CN version factory pre-calibration); minimum measured shaft diameter: 25mm
- Matched CON021 Signal Conditioner Parameters
All electrical, environmental and mounting parameters of matched CON021 conditioner are completely consistent with CON021 parameters listed in PR6424 010-110+CON021 model datasheet
Material Composition & Structural Features
- PR6423 000-101-CN Probe
- Sensing coil: ultra-small diameter copper enameled wire winding, fully sealed with high-temperature two-component epoxy resin
- Probe housing: thin-wall seamless 304 stainless steel tube, CNC precision machined external M8×1 miniature mounting thread, medium 101mm body length for medium depth bearing housing installation
- Connecting cable: double-layer shielded coaxial cable with identical material and structural design as PR6424 series probes
- Cable connector: gold-plated self-locking LEMO aviation plug with anti-vibration locking structure
- Matched CON021 Signal Conditioner
Material composition and structural features fully consistent with CON021 content in PR6424 010-110+CON021 model datasheet
Working Principle
The core eddy current signal conversion working principle of PR6423 000-101-CN miniature probe is completely identical to PR6424 series probes. The China localized -CN version only optimizes factory calibration parameters to adapt to domestic common steel shaft materials, without changing high-frequency electromagnetic field excitation, eddy current induction, coil impedance variation detection and linear voltage demodulation logic of CON021 conditioner. This medium-length miniature probe balances installation depth and measuring range, suitable for most domestic small and medium turbomachinery vibration monitoring projects. The matched CON021 conditioner still retains complete cable open/short-circuit fault self-diagnosis function.
Core Functional Features
- Miniature 8mm sensing head and M8×1 miniature mounting thread, perfectly adapt to narrow reserved mounting holes of small and medium-sized rotating equipment bearing housings
- Standard ±2mm linear measuring range, universal general-purpose range covering most industrial rotating machinery vibration and displacement measuring demands
- Medium 101mm probe body length, suitable for medium depth bearing housing internal installation space
- -CN China localized calibrated version, factory pre-calibrated for domestic mainstream ferromagnetic steel shaft targets, matching domestic DCS and vibration monitoring equipment signal parameters
- Non-contact measuring mode, zero mechanical friction and wear between probe and rotating shaft, long service life
- Measuring signal immune to lubricating oil, water vapor and dust interference in bearing housing gap
- Standard matching with CON021 signal conditioner, factory unified calibration of probe and conditioner to guarantee overall measuring linearity accuracy
- CON021 built-in cable fault self-diagnosis function, timely feed back probe circuit abnormal signal to upper monitoring system
Application Scenarios
- Domestic small and medium steam turbine auxiliary rotating shaft vibration and axial displacement monitoring
- Small industrial centrifugal compressor, medium-size blower and fan rotor radial vibration protection measurement
- Petrochemical plant medium-speed process pump and screw compressor miniature rotor shaft displacement online monitoring
- Domestic hydraulic small turbine generator unit rotating machinery fault early warning diagnosis system
- Small gas turbine auxiliary rotating shaft thrust bearing clearance wear monitoring
- Precision gearbox medium-speed small-diameter gear shaft vibration and eccentricity measurement
Installation Requirements
- Probe Installation Rules
All installation operation rules of PR6423 000-101-CN miniature probe are consistent with probe installation requirements listed in PR6424 010-110+CON021 model datasheet; adjust initial clearance to midpoint of ±2mm linear range before locking anti-loose nuts
- Matched CON021 Conditioner Installation Rules
All DIN rail installation, power supply wiring, signal wiring and grounding rules of CON021 conditioner are completely consistent with conditioner installation requirements listed in PR6424 010-110+CON021 model datasheet
Operation & Maintenance Precautions
All operation and daily maintenance precautions of PR6423 000-101-CN probe and matched CON021 conditioner are consistent with maintenance requirements listed in PR6424 010-110+CON021 model datasheet; during regular calibration, domestic standard 45# steel target shall be used for displacement calibration
