Product Short Description
Product Brief Introduction
Emerson DeltaV distributed control system dedicated field terminal assembly, matched with DeltaV DCS controller analog input card, realizes field 4–20 mA sensor signal terminal wiring, built-in signal surge suppression and overcurrent protection for process industry plant control cabinets.
Description
Complete Technical Specifications
- Signal Electrical Parameters
- Supported Input Signal: 4–20 mA two-wire transmitter loop signal
- Channel Quantity: 8 independent analog input channels per terminal block
- Surge Protection Level: 2 kV ESD, 1 kV surge transient suppression
- Isolation: Each channel independent galvanic isolation
- Operating Power: Passive terminal block without external power supply
- Environmental Index
- Operating Temperature: 0 °C ~ +60 °C control cabinet range
- Protection Grade: IP20 indoor cabinet installation
- Physical Size
- DIN rail mounting terminal block size: 165 mm × 98 mm × 32 mm
- Net Weight: 0.29 kg
Core Function Features
- On-board gas discharge tube surge protection to suppress field lightning induced transient voltage
- Quick plug wiring terminal design for fast sensor cable replacement during maintenance
- Channel short-circuit independent fuse protection, single channel fault does not affect other measuring loops
- Standard DeltaV backplane bus matching, seamless system hardware compatibility
Working Principle
Field sensor 4–20 mA signal enters terminal block independent channel circuits, surge suppression components absorb instantaneous overvoltage interference from field long wiring, current signal transmits to DeltaV analog input card via internal gold-plated bus contacts. Independent micro-fuse cuts off single-channel overcurrent fault to avoid spreading damage to DCS main control card circuit.
Material Composition & Structural Characteristics
- Housing: Flame retardant PC plastic DIN rail shell
- Terminal Conductors: Tinned copper anti-oxidation wiring terminals
- Protection Components: Gas discharge surge tubes, fast-blow miniature fuses integrated per channel
Installation Requirements
- Mount on 35 mm DIN rail inside DeltaV DCS dedicated control cabinet
- Field signal cables use shielded twisted pair, shielding layer cabinet single-point grounding
- Separate analog terminal block cabinet area from high-voltage relay power cabinet with metal isolation partition
Application Scenarios
- Refinery DeltaV distributed control system field pressure/temperature transmitter wiring terminal
- Chemical plant reactor process analog signal centralized wiring cabinet
- Power plant circulating water system DCS analog input terminal assembly
Operation & Usage Precautions
- When replacing blown channel fuses, only use Emerson original matched current rating fuses
- Do not mix analog signal wiring with AC 220 V power wiring on same terminal block row
- Avoid conductive dust accumulation on terminal block metal contacts, clean with dry compressed air semi-annually
