Product Short Description
Product Introduction
The GE CE4002S1T2B5 is a high-density, field-wiring termination block designed exclusively for the Emerson DeltaV M‑series I/O system (formerly GE). It serves as the physical interface between 32‑channel discrete output cards (24 VDC, high‑side) and field devices, providing secure, organized, and fault‑resistant wiring termination. Engineered for direct mounting on DIN rails in control panels, it streamlines installation, reduces wiring errors, and enables hot‑swap I/O card replacement without field rewiring.
Description
Technical Specifications
- Manufacturer: General Electric (GE), Emerson Automation Solutions (DeltaV)
- Model Number: CE4002S1T2B5
- Series: DeltaV M‑series Traditional I/O
- Supported I/O Card: 32‑Channel Discrete Output Card, 24 VDC, High‑Side
- Termination Type: Standard screw‑terminal block
- Number of Channels: 32 (digital output)
- Field Wiring Connection: Screw terminals (16–22 AWG)
- Backplane Interface: DeltaV M‑series LocalBus
- Operating Voltage: 24 VDC nominal (field side)
- Operating Temperature: -40°C to +70°C (-40°F to +158°F)
- Storage Temperature: -55°C to +85°C (-67°F to +185°F)
- Humidity: 5%–95%, non‑condensing
- Protection Class: IP20 (industrial control panel rating)
- Dimensions: 263 mm × 58 mm × 28 mm (10.35 in × 2.28 in × 1.10 in)
- Weight: 0.43 kg (0.95 lbs)
- Mounting: DIN rail mount (compatible with standard EN 60715 rails)
- Certifications: CE, UL/cUL, ATEX II 3G EEx nL IIC T4, FM Class 1 Div 2
Key Features
-
Dedicated 32‑Channel High‑Side DO Termination
- Optimized for DeltaV 32‑channel 24 VDC high‑side discrete output cards
- Each channel provides a dedicated screw terminal for positive and negative field connections
- Eliminates cross‑wiring and simplifies field device connection (solenoids, relays, contactors)
-
Hot‑Swap & Fault‑Tolerant Design
- Supports hot‑swapping of I/O cards without disconnecting field wiring
- Integrated field wiring protection keys prevent insertion of incorrect I/O card types
- Channel‑to‑system isolation (1500 VDC) protects the control system from field‑side electrical faults
-
Robust Industrial‑Grade Construction
- High‑impact, flame‑retardant plastic housing with metal reinforcement
- Conformal coating option available for corrosive, humid, or dusty environments
- Vibration‑resistant screw terminals maintain connection integrity in high‑vibration areas
-
Simplified Installation & Maintenance
- DIN rail mount enables tool‑free installation in standard control panels
- Clearly labeled channel numbers and LED status indicators for each channel
- Compatible with DeltaV EnerVista software for system configuration and diagnostic monitoring
-
Seamless DeltaV System Integration
- Fully compatible with all DeltaV M‑series I/O cards, carriers, and controllers
- Interfaces directly with the DeltaV LocalBus for high‑speed, deterministic communication
- Redundant system configurations supported for maximum availability
Application Scenarios
- Process Industries: Chemical, petrochemical, and pharmaceutical plants for valve, pump, and motor control
- Power Generation: Thermal, hydro, and renewable energy facilities for auxiliary equipment interlocking and control
- Oil & Gas: Upstream drilling, midstream pipelines, and downstream refineries for safety shutdown and process control
- Water & Wastewater Treatment: Municipal and industrial plants for pump, blower, and valve automation
- Manufacturing: Automotive, aerospace, and discrete manufacturing for assembly line and material handling control
- Mining: Surface and underground operations for conveyor, crusher, and hoist control systems
Additional Information
- Condition: Brand new, original factory sealed packaging
- Warranty: 12‑month manufacturer warranty
- Country of Origin: United States
- Lead Time: 4–6 weeks (in‑stock units available)
- Compatibility: Fully compatible with Emerson DeltaV M‑series 32‑channel 24 VDC high‑side discrete output cards
