Product Short Description
- Product Name: Emerson Temperature Monitoring Module
- Product Introduction: Multi-channel temperature acquisition and monitoring module, used for temperature detection of equipment bearings, stator, shell and other parts.
- Technical Specifications: Input Type: PT100 Platinum Resistance; Measuring Range: -100 °C ~ +200 °C; Channel Quantity: 4 channels; Power Supply: 24 V DC.
Description
- Functional Features: Multi-channel synchronous temperature acquisition; signal conversion and compensation; over-temperature alarm; data remote transmission.
- Performance Parameters: Measurement Accuracy: ±0.2 °C; Sampling Cycle: 100 ms; Output Signal: 4 ~ 20 mA; Line Resistance Compensation: Support 3-wire system.
- Material Composition: Shell: **Flame-retardant metal shell»; Internal components: high-precision resistance acquisition chip; Terminal base: high-temperature resistant plastic.
- Structural Characteristics: DIN rail modular design; each channel corresponds to independent terminal group; power and alarm indicator lights are arranged on the front side.
- Working Principle: Collects resistance change signals from PT100 temperature sensors, converts resistance values into standard temperature values through internal circuit and algorithm, outputs temperature data, and sends alarm signal when temperature exceeds limit.
- Advantages & Highlights: Multi-channel integrated design; high temperature measurement precision; automatic line resistance compensation; strong anti-temperature drift ability.
- Applicable Industries: Electric power equipment, petrochemical units, metallurgical furnaces, large mechanical equipment, refrigeration units.
- Model Series: Emerson A6000 Series Machinery Protection Modules
- Installation Requirements: Rail installation inside electrical cabinet; use dedicated PT100 compensation wires for wiring; keep away from heat sources; classify wiring of each channel clearly.
- Usage Notes: Ensure the consistency of sensor and module signal type; avoid long-distance wiring without shielding; calibrate regularly in high-precision application scenarios.
