Description
Technical Specifications
- Model Series: 414AN Series
- Control Type: BV standard control mode
- Rated Power: Industrial standard matching power for 414 series
- Input Voltage: Three-phase industrial AC power supply
- Protection Level: IP20
Functional Features
Stepless motor speed regulation; soft start and soft stop; overvoltage, undervoltage, overload protection; energy-saving operation; multiple communication control modes.
Performance Parameters
- Frequency Regulation Range: 0 ~ rated output frequency
- Start-Stop Performance: No impact soft start
- Overload Capacity: Standard industrial overload protection parameters
Material Composition
Main housing: Flame-retardant engineering plastic + metal heat sink; Internal power module: IGBT power device; Control board: Industrial grade PCB; Wiring terminal: Copper alloy.
Structural Characteristics
Vertical standard cabinet installation structure; upper wiring area, lower heat dissipation area; integrated drive and control unit; built-in heat dissipation fan.
Working Principle
Convert industrial AC power into DC power through rectifier circuit, then invert DC power into AC power with adjustable frequency and voltage via inverter circuit, and change motor rotating speed by adjusting output frequency.
Advantage Highlights
High operation efficiency; obvious energy-saving effect; rich protection functions; stable operation; compact cabinet type, convenient for electrical cabinet integration.
Applicable Industries
Automation production lines, fan and pump equipment, textile machinery, packaging machinery, logistics transmission equipment.
Model Series
ECOVARIO 414AN Frequency Converter Series
Installation Requirements
- Install vertically inside standard industrial electrical cabinet;
- Reserve upper and lower heat dissipation gaps as specified;
- Wiring strictly distinguish strong current and weak current lines to avoid interference;
- Reliable grounding according to electrical specifications.
Usage Notes
- Do not run with the cabinet cover removed for a long time;
- Regularly clean heat sink and fan dust;
- Prohibit overloading and frequent start-stop beyond specification;
- Keep the installation environment dry and well ventilated.
