Product Short Description
Product Overview
MPB1-TP serves as a dedicated hot-pluggable communication expansion accessory engineered exclusively for Eaton XV400 series compact industrial touch HMI units. This module extends the base HMI communication capability by adding an isolated serial interface supporting multiple mainstream industrial serial protocols. It enables data exchange between the HMI and PLCs, variable frequency drives, intelligent sensors, weighing controllers and field monitoring instruments without replacing the main human-machine interface hardware.
Description
Core Technical & Performance Parameters
- Compatible host device: Eaton XV400 series micro touch panels
- Physical interface: Screw-type terminal block, RS485 multi-drop serial bus
- Supported communication protocols: Modbus RTU, Modbus ASCII, Eaton SmartWire-DT auxiliary serial protocol, ASCII free protocol
- Communication baud rate range: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps
- Data format options: 7/8 data bits, even/odd/no parity, 1/2 stop bits
- Galvanic isolation: 2500 Vrms isolation between serial bus circuit and HMI internal logic circuit
- Power supply: Powered passively via HMI internal backplane, no external auxiliary power required
- Maximum communication cable length: 1200 m at 9600 bps; 500 m at 115200 bps
- Supported network topology: Multi-drop bus structure, maximum 31 slave nodes on single bus segment
- Operating temperature: 0 °C ~ +55 °C; storage temperature: -20 °C ~ +70 °C
- Humidity: 5% ~ 95% non-condensing
- Protection class: IP20 (installation inside HMI rear housing)
- Module dimension: Compact PCB form factor matching XV400 expansion slot geometry
Function Features
- Plug-and-play expansion design; after physical installation, communication parameters can be configured directly via HMI programming software without additional driver installation.
- Built-in ESD and surge protection on RS485 signal lines, resisting electrostatic discharge and transient voltage surges from industrial field wiring.
- Automatic send/receive direction control circuit, eliminating external direction control signal wiring for Modbus bus networks.
- Multi-protocol switching via HMI configuration software, realizing seamless connection with third-party Modbus field devices.
- Isolated circuit design effectively eliminates ground loop interference between HMI and remote field instruments, reducing communication packet loss and data error.
- Supports continuous real-time data polling, alarm message acquisition and parameter read-write operations for lower-layer automation equipment.
- Supports terminal resistance enable/disable configuration through software, convenient for matching different serial bus cable characteristics.
Material Composition & Structural Characteristics
- Main circuit board: Multi-layer FR4 industrial printed circuit board with tin-lead free surface treatment
- Isolation components: High-speed digital optocoupler modules separating host side and field bus signal circuits
- Terminal assembly: UL94-V0 flame-retardant PA66 plastic spring screw terminals with anti-loosening structure
- Connector: Gold-plated edge connector for docking with XV400 HMI internal expansion slot, anti-oxidation for long-term vibration environment
- Passive components: High stability resistors and capacitors for serial signal impedance matching
Working Principle
The expansion module communicates with the XV400 HMI main control chip via internal parallel bus. User-configured protocol parameters are stored in onboard non-volatile memory. When the HMI initiates read/write commands to field devices, the module converts internal parallel data frames into standard RS485 serial differential signals and transmits to slave equipment. Returned data from field instruments is captured via differential signal circuit, isolated and converted back into parallel data for the HMI processor. The direction control circuit automatically switches transceiver status to realize half-duplex Modbus communication.
Installation Requirements
- Cut off power supply of XV400 HMI before installation; strictly prohibit hot swapping of expansion modules.
- Align PCB edge connector with HMI rear expansion slot, push the module fully into position and fix with locking screws.
- Use twisted shielded pair cables for RS485 field wiring; connect cable shield to single ground point at HMI side.
- Install terminal resistance at the two extreme ends of long-distance serial bus when communication distance exceeds 300 meters.
- Keep serial signal cables separated from high-current AC power cables with minimum 20 cm clearance to avoid electromagnetic coupling interference.
- Do not bundle RS485 wiring alongside inverter power output cables.
Application Scenarios
Small-scale automated assembly lines, building automation control panels, water treatment local control cabinets, packaging machinery control systems, pump and fan group monitoring, small energy management systems, factory decentralized sensor data collection.
Operation & Maintenance Precautions
- Do not short-circuit RS485 A/B signal terminals; short circuit will permanently damage onboard transceiver chip.
- Regularly check terminal screw tightness every 12 months; loose terminals cause intermittent communication failures.
- When multiple Modbus slave devices exist, reasonably set polling interval to avoid bus congestion and communication timeout faults.
- Avoid operating under ambient temperature above 55°C continuously; high temperature accelerates aging of optocoupler isolation devices.
- Do not use unshielded ordinary cables for long-distance serial communication.
- After power failure, verify protocol parameters if communication is abnormal; unexpected electrostatic impact may lead to parameter loss in extreme environments.
